7 ENGLISH

FUNCTIONAL

DESCRIPTION

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before adjusting or checking function on the tool.

Installing or removing battery

cartridge

CAUTION:

Always switch off the tool before

installing or removing of the battery cartridge.

CAUTION:

Hold the tool and the battery car-

tridge firmly when installing or removing battery

cartridge.

 Failure to hold the tool and the battery

cartridge firmly may cause them to slip off your hands

and result in damage to the tool and battery cartridge

and a personal injury.

►

Fig.1:

1.

 Red indicator

2.

 Button

3.

 Battery cartridge

To remove the battery cartridge, slide it from the tool

while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the

battery cartridge with the groove in the housing and slip

it into place. Insert it all the way until it locks in place

with a little click. If you can see the red indicator on the

upper side of the button, it is not locked completely.

CAUTION:

Always install the battery cartridge

fully until the red indicator cannot be seen.

 If not,

it may accidentally fall out of the tool, causing injury to

you or someone around you.

CAUTION:

Do not install the battery cartridge

forcibly.

 If the cartridge does not slide in easily, it is

not being inserted correctly.

Battery protection system

The tool is equipped with a battery protection system.

This system automatically cuts off power to the motor to

extend battery life.

The tool will automatically stop during operation if the

tool and/or battery are placed under one of the following

conditions:

Overloaded:

The tool is operated in a manner that causes it to draw

an abnormally high current.

In this situation, turn the tool off and stop the application

that caused the tool to become overloaded. Then turn

the tool on to restart.

If the tool does not start, the battery is overheated. In

this situation, let the battery cool before turning the tool

on again.

Low battery voltage:

The remaining battery capacity is too low and the tool

will not operate. If you turn the tool on, the motor runs

again but stops soon. In this situation, remove and

recharge the battery.

Indicating the remaining battery

capacity

Only for battery cartridges with "B" at the end of the

model number

►

Fig.2:

1.

 Indicator lamps

2.

 Check button

Press the check button on the battery cartridge to indicate the remain-

ing battery capacity. The indicator lamps light up for few seconds.

Indicator lamps

Remaining

capacity

Lighted

Off

75% to 100%

50% to 75%

25% to 50%

0% to 25%

NOTE:

 Depending on the conditions of use and the

ambient temperature, the indication may differ slightly

from the actual capacity.

Adjusting depth of cut

CAUTION:

After adjusting the depth of cut,

always tighten the clamping screw securely.

►

Fig.3:

1.

 Clamping screw

2.

 Depth guide

Loosen the clamping screw on the depth guide and

move the base up or down. At the desired depth of cut,

secure the base by tightening the clamping screw.

Bevel cutting

►

Fig.4:

1.

 Clamping screw

2.

 Bevel scale plate

Loosen the clamping screw on the bevel scale plate on the

front of the base. Set for the desired angle (0° - 45°) by tilt-

ing accordingly, then tighten the clamping screw securely.

Sighting

►

Fig.5:

1.

 Cutting line

For straight cuts, align the A position on the front of the base with

your cutting line. For 45° bevel cuts, align the B position with it.

Switch action

CAUTION:

Before installing the battery cartridge into

the tool, always check to see that the switch trigger actuates

properly and returns to the "OFF" position when released.

CAUTION:

Do not pull the switch trigger hard without

pressing the lock-off lever. This can cause switch breakage.

►

Fig.6:

1.

 Lock-off lever

2.

 Switch trigger

To prevent the switch trigger from being accidentally

pulled, a lock-off lever is provided. To start the tool, slide

the lock-off lever and pull the switch trigger. Release the

switch trigger to stop.
