16

 | English

1 609 92A 2AZ | (30.3.16)

Bosch Power Tools

The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.

Products sold in AUS and NZ only

: Use a residual current de-

vice (RCD) with a rated residual current of 30 mA or less.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for lengthways and crossways cut-
ting of wood with straight cutting lines as well as mitre cuts in
wood while resting firmly on the workpiece. With suitable saw
blades, thin-walled non-ferrous metals, e. g., profiles, can al-
so be sawed.
Working ferrous metals is not permitted.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Blade guard

2

Lock-off button for On/Off switch

3

On/Off switch

4

Auxiliary handle (insulated gripping surface)

5

Spindle lock button

6

Scale for mitre angle

7

Wing bolt for parallel guide

8

Wing bolt for bevel-angle preselection

9

Cutting mark, 0 °

10

Cutting mark, 45 °

11

Parallel guide *

12

Retracting blade guard

13

Riving knife  (GKS 85 G)

14

Base plate

15

Lever for retracting blade guard

16

Wing bolt for bevel-angle preselection

17

Chip ejector

18

Handle (insulated gripping surface)

19

Hex key

20

Clamping bolt with washer

21

Clamping flange

22

Saw blade *

23

Mounting flange

24

Saw spindle

25

Screw for attachment of riving knife  (GKS 85 G)

26

Extraction adapter *

27

Fastening screw for extraction adapter  (GKS 85) *

28

Clamping lever for cutting-depth preselection

29

Cutting-depth scale

30

Set of screw clamps *

31

Guide rail *

32

Connection piece *

33

Vacuum hose *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Circular Saw

GKS 85

GKS 85 G

Article number

3 601 E7A 0..

3 601 E7A 9..

Rated power input

W

2 200

2 200

No-load speed

min

-1

5 000

5 000

Rotational speed under load, max.

min

-1

3 500

3 500

Cutting depth, max.

– for  0 °  bevel  angle
– for  45 °  bevel  angle

mm
mm

85
65

85
65

Spindle lock





Constant electronic control

–



Reduced starting current





Base plate dimensions

mm

383 x 170

406 x 208

Saw blade diameter, max.

mm

235

235

Saw blade diameter, min.

mm

230

230

Blade thickness, max.

mm

2.2

2.2

Tooth thickness/setting, max.

mm

3.2

3.2

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
