7

ENGLISH

(Original instructions)

•  Before the cleaning, unplug the charger plug from the

power source. In addition, except the regular cleaning on

your charger, no other maintenance is needed.

•  Regularly use the soft brush or dry cloth to clean the

ventilation slot of the equipment / tools / charger.

•  Regularly use a damp cloth to clean the motor housing.

Please do not use any abrasive cleaning agents or

solvent-based cleansing agents.

•  Regularly open the clamping chuck and tap it gently to

remove any internal dust (after installation).

Replace the carbon brushes (Fig. E)

Lubrication

•  Regularly replace and check the carbon brushes.

Replace it in time when it is worn to the abrasive

boundary line. Keep the carbon brush clean and make it

freely slide in the brushing range. Two brushes shall be

replaced at the same time.

•  Use the cross screwdriver to counterclockwise unscrew

the screws, open the bottom cover(8) with a flat

screwdriver to counterclockwise open the brush

cover(9), you can remove the brush(10)as shown in the

figure E, and put the new brush, and then clockwise

fasten the brush cover(9), finally put the bottom cover(8),

and then use the cross screwdriver to tighten it properly.

•  Open the cap of the lube oil-injection inlet(2), check the

lube oil in the gearbox, if the lube oil is dirty or

insufficient, replace or add the adequate amount of lube

oil provided by the company.

Cleaning

Warning!

 Once the visible dust build-up is found at and/or

around the ventilating ports, immediately flush the dust and

powder within the host shell with clean dry air. To perform

this procedure, wear the approved safety equipment and

dust mask.

Warning!

 It is strictly forbidden to clean the non-metallic

parts of the tool with the solvents or other irritant chemicals.

These chemicals may weaken the materials of these

components. Use a cloth moistened with a mild soapy water

to clean it. Do not let any substance permeate into the tool

and.do not immerse any part of the tool into a liquid.

Technical data

Hammer

STHR272

Power input

W

850

No-load speed

/min

700

Impact rate

BPM

 3400

Impact energy (EPTA)

J

 4.1

Modes

2

Max capacity

Concrete

mm

 26

Steel

mm

 -

Wood

mm

-

Weight

kg

5.1
