6

ENGLISH

(Original instructions)

Warning!

 Before drilling holes in the wall, floor or ceiling,

please check the positions of the wire and steel tube.

Chipping/Chiseling (Fig. B)

•  When the cutting / stripping / removing operation is

conducted, please put the operation modes selector (3)

to position    , the drilling bit, cold chisel and scaling

chisel etc. should be properly used.

Warning!

 Do not rotate the knob when the power tool is

rotating under the load, otherwise it will be damaged.

Hammer drilling (Fig. B)

•  When using the hammer driller to drill holes on the

masonry and concrete surfaces, the operation mode

selector (3) should be set to position     .

•  The drilling bit should be aligned to the drilling position,

and then press the switch button to achieve the best

effect. Keep the power tool be positioned correctly,

prevent it from deviating the hole.

•  When the fragments plug the borehole or powders,

please do not apply further pressure, and make the tool

rotate in an idling state, then gradually take out the

drilling bit from the hole. Repeat the said steps for

several times, the plugged hole can be clean, and then

resume the normal drilling.

Warning!

 When the drilling bit begins to break down the

reinforced concrete or hit the steel bar inside the concrete,

the power tool may have dangerous reaction force. Please

always keep balance, stable posture and tightly grip the tool,

to prevent from generating the dangerous reaction force.

When the concrete is chiseled, the distance between the two

points of one chiseling shall not be too much away from the

edge, which shall be about 8cm or so, define the distance

through finding the cracking strength of the concrete.

Overload coupling device

If the drilling bit is clamped or hooked up, the driving force

transmitted to the drill shaft will be cut off. A huge force will

occur, so two hands must tightly grip the power tool when it

is in operation, and ensure that the operator is standing in a

stable and fixed position.

Select the depth of holes to be drilled (Fig. C)

A depth gauge is an easy to use ruler to ensure that the

drilling depth is consistent. Unlock the side handle, adjust

the depth gauge according to the required depth, and then

tighten the side handle.

•  Unfasten the side handle (6) by turning

counter-clockwise the grip.

•  Set the depth stop (7) to the desired position. The

maximum depth of the drilled hole shall equal to the

distance between the tip of drilling bit and the front end

of the depth stop.

•  Tighten the side handle by turning the grip clockwise.

Switch on and off

Warning!

 Before inserting the plug, please confirm whether

the switch can trigger freely or not, whether it can return to

the original position after releasing.

•  Press the switch button (1), the power tool can be

started immediately.

•  Release the button (1), the tool stops rotating.

Accessories

The performance of an electric tool depends on its

accessories. STANLEY accessories are designed according

to high quality standards, to enhance the performance of

electric tool. The use of these accessories can help you

conveniently operate the tool.

Maintenance

The STANLEY cord / cordless appliance / tools are of

sophisticated design, can be used for a long time, and only

little maintenance is needed. To obtain consistent

satisfactory use, proper maintenance and regular cleaning of

the tools are necessary.

Warning!

 Before performing any maintenance work on the

cord / cordless electric tools, the following points must be

implemented:

•  Switch off the power of the equipment / tools and pull off

the plug;

•  If the equipment / tools are equipped with independent

battery pack, please turn off the power and remove the

battery pack from the equipment / tools.

•  If the equipment / tools are equipped with an integrated

battery, please run out the battery, before turning off its

power.
