www.timberk.com • electric convector heater
7
Fig. 6
Fig. 7
7. CONVECTOR HEATER CONTROL
8. SERVICE
Convector heaters of series ТЕС.Е3 М, TEC.E5 M are equipped with a
mechanical thermostat.
Control panel
The appliance should be washed regularly to remove dust and dirt from
external surfaces, since it affects the efficiency of its work and temperature
parameters of heating.
Before preventive maintenance shut off the appliance and unplug it, let it
cool down and then wipe its surface with a soft, slightly wet cloth. It is not
recommended to wash it with detergents, including agents with abrasive
contents. Exclude damaging of the appliance with sharp objects, because
scratches on its painted surface may result in emergence of rust.
Rear surface of the convector heater should also be cleaned of dust and
dirt. For that it is necessary to detach the appliance from the bracket and
after cleaning return it to original position.
Preventive cleaning should be performed regularly to maintain good
technical condition of the convector and keep its appearance for many
years.
1. Thermostat knob
Used to set a desired temperature in the room.
2. Indicator lamp «POWER»
Flashes when the appliance is connected to power network.
З. Two-key switch, with indication
Used to choose the following modes of heating power: mode 1
(low power), mode 2 (average power), mode 3 (high power).
Convector heater operation
1. Switching on
• Connect the convector heater to power network by plugging it into the
power outlet. The indicator lamp «POWER» will flash.
•
Press the switch key to switch the convector on.
2. Selection of heating power mode
Press the key«1» to select low heating power, it will be indicated by a lamp
of key «1».
Press the key«2» to select average heating power, it will be indicated by a
lamp of key «2».
Press the keys«1» and «2» to select high heating power, it will be indicated
by lamps of both keys.
3. Setting of temperature**
Open a transparent plastic protection cap on the control panel and provide
the access to thermostat knob.
Turn the thermostat knob clockwise up to the stop. At that, if temperature
in the room is lower than the set one, the indicator lamp in the switch
will flash. When temperature in the room will reach the desired level, turn
the thermostat knob counterclockwise up to disconnection. The indicator
lamp in the switch will go out. Then the thermostat will maintain the set
temperature switching the convector on and off periodically.
In especially cold weather the convector may be unable to cope with
heating of the room. In such a case the thermostat knob should be set to
the level, which is a little higher than the desired one.
4. Switching off
Set the key of the heating switch to the «О» position and unplug the
appliance. At that, the indicator lamp «POWER» on the control panel will
go out.
1
2
3
** «Comfort» mode, which can be selected with the use of the thermostat knob, corresponds
to the most comfortable temperature in the room.
