www.timberk.com • electric convector heater

4

3. OPERATIONAL CHARACTERISTICS

Table 1

Fig. 1

Technical characteristics

Technical characteristics of the convector are given in Table 1.

For a detailed description of technical parameters and characteristics go to

www.timberk.com or contact TIMBERK official dealers.

IMPORTANT!

The manufacturer reserves the right to change the set-list

of the device (including liquid and powder components)

for different supplies without prior notice. The changes

either in no way influence the basic technical parameters

of the device or may improve them, and also not violate

the legislation or quality standards of the countries of

manufacture, transit and selling.
The changes in the set-list may result in changing of the

weight and dimensions of the device, but not more than

by +\- 5-20% (depending on the product category)

Operating principle

Cool air in under part of the room pass through the heating element of the

convector. Then the heat flow expands, uprushes through the outlet grill

and extends over the room. At that, direction of the flow set by the grill

inclination creates a favourable, accelerated circulation of warm air inside

the room without dispersing it on walls and windows.

Key features

1. Combination of convection effect (hence the name of ‘convector’) with

soft heat emission makes the heater an efficient source of heat energy with

increasing number of users.
2. Simple and efficient opportunities for control over temperature conditions.
3. High-precision controllable thermostat.
4. Quick self-repayment due to high efficiency and rate of set temperature

development.
5. Simplicity of installation, operating reliability and servicing ease.
6. Three-mode heating for energy saving.
7. Built-in drop sensor will disconnect the convector if it is deflected from

vertical position  e.g. if it is accidentally overturned when used on legs.

Convector dimensions depending on power (Fig.1)

Convector heaters of the Timberk series are divided by maximum power

consumption of heating element and differ from each other by the length,

while having equal height and depth. (Standard overall height of all the

appliances is 440 mm). This scheme for arrangement of overall dimensions

allows to use Timberk convectors with various power in the same room

without breaking of familiar symmetry.

455 mm

1000 W

1500 W

2000 W

455 mm

615 mm

775 mm

Model

Rated

voltage,

V/Hz

Operating power

consumption (on

modes), W

Rated

curren, A

Net

weight,

kg

Overall

dimensions,

mm

Waterproof

class

Electric

protection

class

TEC. E3 M 1000

~220-

240/50

450/550/1000

4.5

3.6

440х455х130

IP24

Class I

TEC. E3 M 1500

~220-

240/50

650/850/1500

6.8

4.3

440х615х130

IP24

Class I

TEC. E3 M 2000

~220-

240/50

850/1150/2000

9.1

5.2

440х775х130

IP24

Class I

TEC. E5 M 1000

~220-

240/50

450/550/1000

4.5

3.6

440х455х130

IP24

Class I

TEC. E5 M 1500

~220-

240/50

650/850/1500

6.8

4.3

440х615х130

IP24

Class I

TEC. E5 M 2000

~220-

240/50

850/1150/2000

9.1

5.2

440х775х130

IP24

Class I
