www.timberk.com • electric ceiling heater

3

3. WORKING  PARAMETERS

Operation principle

The infrared heater is an appliance with an electric heating element and

radiating boards, which upon heating emit heat to the environment via

directed infrared radiation. Radiant energy is absorbed by the surrounding

12. It is prohibited to use the heater in rooms with explosive, dusty, or

corrosive environment.
13. Exclude operation of the heater without grounding.
14. It is prohibited to switch on and use the heater with removed cover.
15. It is prohibited to install and use the heater in bathrooms, showers, or

near swimming pools, where water jets and drops may directly get onto the

appliance surface, when it is switched on.
16.   It is prohibited to use the heater in dusty rooms and during redecoration.
17.  It is prohibited to touch the heater radiating boards.
18.  Use the heater only as described in this Manual. Any other use not

recommended by the manufacturer may lead to fire, electric shock, or

injuries of people.
19.  Never clean the heater, when it is connected to the electric mains, and

do not wipe the heater radiating boards with flammable liquids during its

operation.
20. For normal operation of the heater, the mains voltage should be

sufficient and the mains specifications should strictly correspond to the

technical parameters indicated on the appliance body. If necessary, clarify

the specifications of your mains from the electricity supplier.
21.  Install and operate the heater in strictly horizontal position on the ceiling

or ceiling structural elements. At that, thermal resistance of the ceiling

coating material should be at least 80 °C.
22. It is prohibited to install the appliance in immediate proximity to an

electric socket. This may result in its overheating causing an emergency

situation.
23. The appliance is not designed for use by people (including children)

with limited physical, sensory, or mental capabilities and having insufficient

experience/knowledge, if they are not supervised and instructed on use of

the device by a person responsible for their safety. It is necessary to watch

that children do not play with the heater.

surfaces and it heats them being transformed to thermal energy. Surface

temperature of objects can be different depending on their absorbing

properties (surface color, material), incidence angle of infrared beams,

surface shape and area. Surfaces also release some heat to air. At that,

heated air flows up to the ceiling and gradually cools down. As a result, air

temperature at the head level of a standing person appears below the floor

temperature by 1-2 °C.

Main features

1. Significant economic effect as compared to convectional heating, where

heat is significantly consumed for heating of unused roof space (first, air

is heated throughout the room volume, and then air heats objects and

surfaces in the room).
2. Capability of local heating only for those areas in the room, where it is

necessary, without heating of the whole room volume.
3. Low air temperature in the room at comfortable temperature on surfaces

of objects, floor, and walls creates the freshness effect  air is not dried up.
4. Low convection (thermal movement of air volumes) reduces amount of

dust kicked up from the floor.
5. Absence of the burnt air effect contrary to heaters with high temperature

of the work surface.
6. You can buy & install additionally the following: Block of Remote Control

together with Remote Control Handheld. This kind of block is available for

TCH A1N, TCH A1B series. Remote Control Block can switch on/off the

heater, choose power mode (from 1 to 2), and also use timer settings.

Using Remote Control, you will get more options than simple ceiling heater

can provide like base function set.

Area of application

Infrared heaters are designed for general, additional, and local heating

of industrial, production, utility, and similar rooms (flats, offices, trade

enterprises, exercise rooms, educational institutions, public catering

enterprises, storage facilities, hangars, agricultural facilities, etc.).
When these heaters are used in day-care services  they can be used only

for additional heating.
