11

wall using adhesive tape and punch in the marked points (see

fig.7).  For  fixing  the  appliance  at  the  wall,  drill  four  holes  with  a

5  mm  diameter  bit  and  fix  the  wall  bracket  with  the  dowels  and

screws that you find in the box (fig.2). Then fix the appliance to the

wall bracket using the 2 screws and the 2 half rings (fig.2). Check

that the arrows on the wall bracket are turned up.

•

A chain suspended  version (768S)

. Before drilling the holes for

the dowels, be sure that the ceiling is solid and that you are far

from water tubes or electrical wires Fix the buttonhole dowels at

the ceiling at a distance of about 55 cm. Fix the 4 half rings a the

pipe  of  the  appliance,  being  sure  that  the  chain  is  fixed  with  the

screws (fig.3). The 4 half rings should be at the opposite sides of

the pipe, for the best stability. Ensure that the chains are securely

mounted as this application is designed for overhead use.

•

A version for mounting on upright (768P)

. The upright must be

from  20  up  to  60  mm  in  diameter.  For  fixing  it,  please  see  fig.  4.

The upright bracket is studied for holding one appliance or two of

them in opposite position.

Before fixing the appliance on the upright, please ensure that

it is stable and solid. Preferably, use the upright that can be

ordered as accessory (cod. 002473). The feet must be opened

as far as the white evidenced line on the inferior tube reaches the

junction of the feet. Fix the feet to the ground in a proper way, and

then fix the upright to the ground using the chain (fig.5).
Ensure that the supply cable is well mounted and that it does not

come into contact with the reflector of the heater or that it does not

trail into the heated area. The supply cable can be fixed to the metal

pipe behind the reflector with plastic wrappers.

4.  USE

The Fiore range consists of a 1200 W heater and an 1800 W heater.

The essential element of the heater is the halogen filled quartz linear

lamp with a tungsten element. The heater operates at full output al-

most immediately. The heating reaches a distance of about 3 meters

in front of the appliance.
