7.

Electric convector

EN

22. Use convector only as described in this manual. Any other use not recommended by the man-

ufacturer and may cause ire, electric shock or injury to persons.

23. Do not attempt to clean the convector when plugged into an outlet. Not allow convector im-
merse in water. Never pull the power cord.

24. To avoid overheating and the risk of ire and damage internal electrical network, do not change

the length of the power cord and do not connect device through an electrical extenders. However,
you can use an extension if its parameters correspond to the performance of the device and if it is
not used by other power consumers.

25.  For  normal  operation  of  the  device  power  voltage  level  must  be  suicient,  and  its  technical

parameters must be in strict accordance with technical data given on the unit. If necessary, ask
network provider for characteristics of their electricity.
26. Install and operate the appliance in upright position. Prohibited to operate the device in a
horizontal or inclined position.
27. The device must be installed so that the panel could not be available for a person who is direct-
ly in the bathroom (in contact with water) or take a shower.
28. Do not install the unit directly under the wall outlet or allow the hot air from the outlet touch
power cord. This can cause them to overheat, creating an emergency situation.
29. The device is not intended for use by persons (including children) with reduced physical, senso-

ry or mental capabilities, with insuicient experience and knowledge, unless they are under super

-

vision and have not received instructions on the use of appliance by a person responsible for their
safety. Necessary to make sure that children do not play with convector.

3. DISPOSAL

Detailed information on the recycling can be obtained from representative of the local authority.

Service life of the device speciied in the warranty card.

4. ASSEMBLY AND INSTALLATION

Wall installation

1. Uncover the original packaging and carefully remove device from it.
2. Remove any foam seals on the edges of the device and release it from polyethylene.
3. Determine the location for the convector in compliance with the minimum distance from the

object and the loor.

4. Mark the height at which you must install the convector and put labels in visible ixing holes.

5. Drill holes in the wall of the required diameter, insert the dowels*, tighten the set screws*.
6. Attach the mounting brackets to the cover of the unit with the mounting screws.
7. Perform installation on the wall convector, setting the screws installed in the wall brackets with
the holes that are installed on the device.

8. Check the installation. Convector should it snugly against the wall.

* May not be included in delivery set

Fig. 3                                                            Fig. 4                                         Fig. 5
