Hyundai H-HV1-15-UI563 - Инструкция по эксплуатации - Страница 11

10.

Electric convector

EN

Press the button «x-heat», when the appliance is working, it starts working in high power.
4. Button «eco»
Press the button «eco», when the appliance is working, it starts working in low power.
5. Button «AF»
Press the «AF» button, the light is working, the appliance would be in anti-freeze mode. Press the
button «AF» again, the appliance would be out of Anti-freeze mode.
6. Button «mute»

Press the «mute», the warning tone is of. Press the button «mute» again, the warning tone is on.

7. Button «x-smart»
Press the button «x-smart», the appliance would be on smart mode:

•  When  the  setting  temperature  is  higher  than  current  temperature  of  5  degrees,  it  starts

working in high power.

• When the setting temperature is higher than current temperature 3 degrees or the setting

temperature is lower than current temperature 5 degrees, it starts working in middle power.

• When the setting temperature is lower than current temperature 3 degrees, it starts working

in low power.

8. Button «light»
Press the button «light», the appliance would be on night mode. The light display, display screen

will turn of.

Press the button «light» again, the appliance would be out of night mode.
9. Button «up» and «down»

•  Press  the  button  «up»  or  «down»,  it  would  increase  or  decrease  the  temperature  settings

(default settings are 25 degrees).

• When set a temperature or timer, if no any setting action in 3 seconds, the timer would be

conirmed.

• When the current temperature is higher than setting temperature of 1 degree, the appliance

will be power of.

• When the current temperature is lower than setting temperature of 1 degree, the appliance

will be power on.

10. Button «timer on»
When in standby, press the button of «timer on», the display screen show number 1 for power on,
press the button «up» again, the display screen would show number 2, the max timer is 24 hours,
press the button of «down», the number would be decrease 1.

11. Button «timer of»
When in power on, press the button of «timer of», the display screen show number 1 for power of
by alarm, the light would be of in the same time, press the button «up» again, the display screen

would show number 2, the max timer is 24 hours, and press the button of «down», the number
would decrease 1.
12. Function «Child lock»

• Press the button «up»/«down» for 3 second, the keyboard lock will be on, the light of «lock»

would be on, the screen would be lashing, it will become to be the previous setting ater 5

seconds; when the keyboard is on, any key is no working.

• For unlock press «up»/«down» for 3 seconds again, the appliance would be unlocked.

13. LED-display
Displays the current temperature value or time settings.
14. «Power» indicator
Lights up when starts heating mode
15. «Standby» indicator
Lights up when convector connecting to electric main
16. «Lock» indicator
Lights up when control panel is locked
17. «NSV» indicator
Lights up when it tests the voltage when the product starts working, if the voltage  below ~180V
or over ~240V, the lamp are light.
18. «ELCB» indicator
Lights up when it tests the grounding function when the product starts working, if it isn’t connect
