9.

Electric convector

EN

1. Inclusion
1.1 Connect the convector to the mains by inserting the plug into the outlet.

2. Selecting the heating power
2.1 Turn the knob in the heating mode position «I» to select low power heating.
2.2 Turn the selector knob to position the heating mode «II» to select the average heating power.
2.3 Turn the selector knob to position the heating mode «III» to select a high heating power.

3. Setting the temperature
3.1 Turn the thermostat knob clockwise until it stops. When the room temperature reaches the

desired level, turn the thermostat knob counter-clockwise to turn of the meter. Now the thermo

-

stat will maintain the set temperature, periodically enabling and disabling convector.

4. Shutdown
4.1 Set the mode switch «OFF» and disconnect the appliance from the mains.

ATTENTION!

In order to increase the operational life of the convector is recom-

mended to note the order unit is switched of. Shutting down the output

without pre-cooling of the heating elements can cause overheating and
premature failure.

For models:

H-HV2-10-UI565
H-HV2-15-UI566
H-HV2-20-UI567
H-HV3-10-UI568
H-HV3-15-UI569
H-HV3-20-UI570

Control panel

4

1

6

7

8

9

5

2

10

3

11

13

1. Button «power»
Press the button «power», when the appliance is not working, it starts working by default in Low
power.
2. Button «normal»
Press the button «normal», when the appliance is working, it starts working in middle power.
3. Button «x-heat»

Fig. 7
