Display indications

467 777_a

21

Display indicator Switching condition

Function / actions

NORMAL X
Flow rate

98 m3

Pump running.

Total volume of water conveyed:

press MODE

button. Displays the volume of water already con-

veyed. Rest not possible.

Running text TOTAL VOLUME

NORMAL X
Part volume

98 m3

Pump running.

Part volume:

 Push the MODE button. Displays

the part volume of water already conveyed. Re-

set push the SET button for approx. 3 seconds.

Running text PART VOLUME

eco X
Mode

3.0 BAR

Pump running or switched

off.

Push the MODE button several times until ECO

MODE appears in the display. Now the pump

switches off earlier (energy-saving mode). See

"Commissioning" on Page 7

eco X
Pressure

3.0 BAR

Pump running or switched

off.

Press the SET button. ECO PRESSURE appears

in the display. The energy-saving mode is swit-

ched on.

NORMAL X
Mode

0.0 m3/H

Pump running or switched

off.

Push the MODE button several times until NOR-

MAL- MODE appears in the display (29).

NORMAL X
Pressure

3.0 BAR

Pump running or switched

off.

Push the SET button until NORMAL X and

PRESSURE appear in the display (29). Switch-

off pressure is increased again.

Warning messages

Display indicator Cause

Actions

ALARM
Top up

1.2 BAR

ALARM
Air pressure

1.5 BAR

Boiler pressure too low. Wa-

ter level too low

Running text PART VOLUME

request for top-up

with air to 1.5 bar. Confirm with the SET button.

Pump starts again.

Running text AIR PRESSURE OK

NORMAL X
Drain

1.5 BAR

Air topped up to above 1.8

bar.

Let air off to 1.5 bar. Once the pressure has been

let off down to 1.5 bar, start the pump again by

pushing the SET button.

Running text LET OFF TO 1.5 BAR
