Display indications

20

HWA 5000/6000 FMS Premium

Normal operation mode

Display indicator Switching condition

Function / actions

GERMAN

Pump running or switched

off

Press the MODE button for longer than 3 se-

conds, the operating language is activated.

Change the operating language by pressing the

MODE button (30). Confirm the new language by

pressing the SET button

NORMAL X
Pressure

1.5 BAR

Pump switches on and starts

to draw water.

Initial commissioning

 Pump filled with water,

suction and pressure side connected, water pre-

sent on the suction side. Pump connected to

mains. Closing off devices in the pressure line

are open.

A rotating X behind the normal symbolises that the pump is ON

ALARM
Top up

1.2 BAR

Pump does not switch on

after self-test. In operation

mode, the pump does not

switch on.

Top up with air and then press the SET button.

Carry out the initial commissioning again. For the

air pressure see technical data Page 3

Running text TOP UP 1.5 BAR

ALARM
Water supply

1.5 BAR

Pump switches off. Dry run-

ning after 90 seconds

Check the suction line and then press the SET

button. Carry out the initial commissioning again.

Running text CHECK WATER INFEED

NORMAL X
Pressure

3.2 BAR

Pump running.

Pump delivering water. Storage vessel being fil-

led. Part of the water is being drawn off.

NORMAL 0
Pressure

4.0 BAR

Pump switches off.

Pump has achieved the set switch-off pressure.

NORMAL X
Pressure

2.0 BAR

Pump switches on

Pump has achieved the set switch-on pressure.

Additional functions

Display indicator Switching condition

Function / actions

NORMAL X
Flow rate

3600 L/M

Pump running.

Flow rate:

press the MODE button until the flow

rate appears.

Running text FLOW RATE
