02/ 2020
BENNING MM 7-1
19
7.4 DC current ranges
Overload protection:
- 440 mA (1000 V) fuse, 11 kA, rapid on mA input
- 11 A (1000 V) fuse, 30 kA, rapid on 10 A input
Max. measuring time:
- 10 A range: 3 minutes (pause > 20 minutes)
- 600 mA range: 10 minutes (pause > 20 minutes)
Measuring range
Resolution
Measurement accuracy
60 mA
10 µA
± (0.8 % of reading + 5 digits)
600 mA
100 µA
± (0.8 % of reading + 5 digits)
6 A
1 mA
± (0.8 % of reading + 5 digits)
10 A
10 mA
± (0.8 % of reading + 5 digits)
7.5 AC/ AC+DC current ranges
The measurement value is obtained as a true RMS value and displayed as
such. With non-sinusoidal curves, the value displayed is less accurate. This
results in an additional error for the following crest factors:
Crest factor of 1.4 to 2.0, additional error + 1.0 %.
Crest factor of 2.0 to 2.5, additional error + 2.5 %
Crest factor of 2.5 to 3.0, additional error + 4.0 %
Overload protection:
- 440 mA (1000 V) fuse, 11 kA, rapid on mA input
- 11 A (1000 V) fuse, 30 kA, rapid on 10 A input
Max. measuring time:
- 10 A range: 3 minutes (pause > 20 minutes)
- 600 mA range: 10 minutes (pause > 20 minutes)
AC Measuring range
Resolution
Measurement accuracy
in frequency range 50 Hz - 1 kHz
60 mA
10 µA
± (1.2 % of reading + 5 digits)
600 mA
100 µA
± (1.2 % of reading + 5 digits)
6 A
1 mA
± (1.2 % of reading + 5 digits)
10 A
10 mA
± (1.2 % of reading + 5 digits)
AC+DC Measuring range
Measurement accuracy in frequency range 50 Hz - 1 kHz
mA
± (2 % of reading + 10 digits)
A
± (2 % of reading + 10 digits)
7.6 Resistance ranges
Overload protection: 1000
V
AC/ DC
Measuring
range
Resolution
Measurement accuracy
Max. meas.
current
Max. no-load
voltage
600 Ω
0.1 Ω
± (0.8 % of reading + 5 digits)
100 µA
2.5 V
6 kΩ
1 Ω
± (0.8 % of reading + 5 digits)
100 µA
2.5 V
60 kΩ
10 Ω
± (0.8 % of reading + 5 digits)
60 µA
0.6 V
600 kΩ
100 Ω
± (0.8 % of reading + 5 digits)
6 µA
0.6 V
6 MΩ
1 kΩ
± (0.8 % of reading + 5 digits)
600 nA
0.6 V
40 MΩ*
10 kΩ
± (1.0 % of reading + 5 digits)
60 nA
0.6 V
* Measured values > 10 MΩ might cause changing values on the display
(max. ± 50 digits).
7.7 Diode testing
Overload protection: 1000
V
AC/ DC
Measuring
range
Resolution Measurement accuracy Max. meas. current
Max. no-load
voltage
2 V
1 mV ± (1.5 % of reading + 5 digits)
0.1 mA
2.5 V
7.8 Continuity testing
Overload protection: 1000
V
AC/ DC
The built-in buzzer sounds in the case of a resistance R less than 30 Ω up
to 100 Ω. For a resistance R higher than 100 Ω, the buzzer does not emit an
acoustic signal.
