05/ 2019
BENNING MM 4
13
7.2 AC voltage ranges
The input resistance is 9 MΩ parallel 100 pF. The reading is obtained by mean-
value rectification and indicated as effective value
Measuring range Resolution
Accuracy
Accuracy overload
protection
4.2 V
1 mV
± (1.5 % of reading + 5 digits)
in frequency range 40 Hz - 300 Hz
600 V
eff
600
V
DC
42 V
10 mV
± (1.5 % of reading + 5 digits)
in frequency range 40 Hz - 500 Hz
600 V
eff
600
V
DC
420 V
100 mV
± (1.5 % of reading + 5 digits)
in frequency range 40 Hz - 500 Hz
600 V
eff
600
V
DC
600 V
1 V
± (1.5 % of reading + 5 digits)
in frequency range 40 Hz - 500 Hz
600 V
eff
600
V
DC
7.3 Resistance ranges
No-load voltage: approx. 1.3 V - 3.3 V, max. test current 2.5 mA.
42 MΩ-range, response time approx. 20 s
Measuring range Resolution
Accuracy
Accuracy overload
protection
420 Ω
0,1 Ω
± (1.2 % of reading + 8 digits)
600 V
eff
600
V
DC
4,2 kΩ
1 Ω
± (0.9 % of reading + 4 digits)
600 V
eff
600
V
DC
42 kΩ
10 Ω
± (0.9 % of reading + 4 digits)
600 V
eff
600
V
DC
420 kΩ
100 Ω
± (1.2 % of reading + 4 digits)
600 V
eff
600
V
DC
4,2 MΩ
1 kΩ
± (1.2 % of reading + 4 digits)
600 V
eff
600
V
DC
42 MΩ
10 kΩ
± (3.0 % of reading + 8 digits)
600 V
eff
600
V
DC
7.4 Diode testing
The stated measurement accuracy applies in the range between 0.4 V and
0.8 V.
Overload protection for diode testing: 600 V
eff
/ 600 V
DC
Measuring
range
Resolution
Accuracy
max. meas.
current
Max. no-load
voltage
0.1 mV
± (1.5 % of reading + 5 digits)
1,5 mA
3,3 V
7.5 Continuity testing
The integrated buzzer sounds at resistances R < 50 Ω.
7.6 AC ranges
(Multimeter with current transducer attachment. Current transducer grips single
live conductor wire).
Measurement accuracy is ± (% of reading + number of digits) at a temperature
of 23 °C ± 5 °C.
Max. current of enclosed current transducer 300 A!
Measuring range
Resolution
Output voltage
Accuracy
300 A
0.1 A
1 mV/ 0.1 A
± (1.5 % of reading + 5 digits)
in frequency range 40 Hz - 300 Hz
8. Measuring with the BENNING MM 4
8.1 Preparation for measurement
Store and use the BENNING MM 4 only under the correct temperature condi-
tions specified. Always avoid prolonged exposure to sunlight.
- Check nominal voltage and current data on the black safety test lead and red
test probe. The black test lead and the red test probes supplied correspond
to the BENNING MM 4 in nominal voltage and nominal current.
- Check insulation of the safety test lead and red test probe. If the insulation
is damaged, discard the lead and test probes immediately.
- Check the continuity of the safety test lead. If the conductor in the safety
