– 12

This high-pressure cleaner is suitable for sucking up
surface water, e.g. from water butts or ponds, with the
KÄRCHER SH 5 suction hose (for maximum suction
height see Technical data).



Screw the suction hose into the water connection of
the appliance and insert it into the water source
(e.g. rainwater drum).



Turn on the appliance “I/ON”.



Unlock the lever of the trigger gun.



Pull on the lever of the trigger gun; the device will
switch on.



Let the appliance work until the water exits at the
hand spray gun without bubbles (max. 2 minutes).



Release the lever of the trigger gun.



Lock the lever of the trigger gun.

Note

: After 2 minutes of dry running, the device shuts

off automatically. For information on restarting, see the
"Troubleshooting" chapter.

몇

CAUTION

Keep a distance of at least 30 cm when using the jet for
cleaning painted surfaces to avoid damage.

ATTENTION

Car tyres, paint or sensitive surfaces such as wood
should not be cleaned with the dirt blaster, as there is a
risk of damage.

Illustration



Push the spray lance into the trigger gun and fasten
it by a 90° rotation.



Turn on the appliance “I/ON”.



Unlock the lever of the trigger gun.



Pull on the lever of the trigger gun; the device will
switch on.
The working mode is shown on the high-pressure
gun display.

Note:

 The battery pack takes a short while to activate;

the device will start after 4 seconds at the most.

Note:

 The battery pack display shows the remaining run

time while the device is in operation.

Note:

 Detergent can only be added when the device is

operated in low pressure mode.



DANGER

When using detergents, the material data safety sheet
issued by the detergent manufacturer must be adhered
to, especially the instructions regarding personal pro-
tective equipment.



Pull detergent suction hose as far as is required out
of the housing.



Suspend end of detergent suction hose in a con-
tainer filled with detergent.



Detach spray lance from the trigger gun. Work only
with the trigger gun.
Working mode: MIX

Note:

 This will mix the detergent with the water stream.



Spray the detergent sparingly on the dry surface
and allow it to react, but not to dry.



Spray off loosened dirt with the high pressure jet.



Release the lever of the trigger gun.

Note:

 Release the lever of the trigger gun; the de-

vice will switch off again. High pressure remains in
the system.



Lock the lever of the trigger gun.



During longer breaks (more than 5 minutes), also
turn the appliance off using the "0/OFF" switch.

몇

CAUTION

Only separate the high-pressure hose from the trigger
gun or the device when there is no pressure in the sys-
tem.



After operation with detergent: Run the machine for
approximately 1 minute for a clear rinse.



Release the lever of the trigger gun.



Turn off the appliance "0/OFF".



Turn off tap.



Press the lever on the trigger gun to release any re-
maining pressure in the system.



Lock the lever of the trigger gun.



Detach the appliance from the water supply.

Remove the battery pack from the device after comple-
tion of the work.
Illustration



Press the lock downwards.



Pull the battery pack forwards.



Recharge battery pack after work.

Note:

 Also charge partly discharged battery packs after

use.

몇

CAUTION

Risk of personal injury or damage!
Mind the weight of the appliance during transport.



Lift appliance by the carrying handle and carry it.



Secure the appliance against shifting and tipping
over.

The lithium-ion battery is subject to the requirements of
dangerous goods regulations and can be transported by
the user in public traffic areas without any further restric-
tions.
When shipping by third parties (transport companies),
special requirements for packaging and labelling must
be observed.
Only send the battery if the casing is undamaged. Tape
off open contacts and pack the battery tightly and se-
curely. It must not be able to move in the packaging.
Please also observe the national regulations.

Drawing in water from open reservoirs

Deaerating the appliance

Operation

High pressure operation

Operation with detergent

Recommended cleaning method

Interrupting operation

Finish operation

Removing the battery pack

Transport

When transporting by hand

When transporting in vehicles

Battery pack
