– 9
If the malfunction occurs repeatedly, have the de-
vice checked by the customer service.
Voltage reduction due to weak mains supply or when
using an extension cable.
Upon switch-on, push the lever of the trigger gun
first and then switch the power switch to "I/ON".
Check setting at the spray lance.
Check water supply for adequate delivery rate.
Pull out the sieve in the water connection using flat-
nose pliers and clean under running water.
Remove air from appliance before operation.
Switch on the appliance without connection the HP
hose (max. 2 minutes) and run it until the water dis-
charging from the HP outlet is free of bubbles.
Switch off appliance and reconnect HP hose.
Clean high-pressure nozzle: Remove dirt and de-
bris from the nozzle bore, using a needle and rinse
through with water from the front.
Check water flow quantity.
Dropwise leakage of the device is normal for tech-
nical reasons. If the leakage increases contact the
authorized customer service.
Use Vario Power spray lance.
Turn the spray lance to "Mix" position.
Check whether the Plug 'n' Clean detergent bottle
is placed into the detergent connection facing
down.
Check / replace the batteries
The warranty terms published by the relevant sales
company are applicable in each country. We will repair
potential failures of your appliance within the warranty
period free of charge, provided that such failure is
caused by faulty material or defects in manufacturing. In
the event of a warranty claim please contact your dealer
or the nearest authorized Customer Service centre.
Please submit the proof of purchase.
Addresses can be found under:
www.kaercher.com/dealersearch
Appliance does not start, motor hums
Pressure does not build up in the appliance
Strong pressure fluctuations
Appliance is leaking
No detergent infeed
No pressure indicator on the trigger gun
Warranty
Technical specifications
Electrical connection
Voltage
230
1~50
V
Hz
Connected load
1,8 kW
Protection class
IP X5
Protective class
I
Mains fuse (slow-blow)
10 A
Water connection
Max. feed pressure
1,2 MPa
Max. feed temperature
40 °C
Min. feed volume
10 l/min
Max. Suction height
0,5 m
Performance data
Working pressure
11 MPa
Max. permissible pressure
13 MPa
Water flow rate
6,3 l/min
Max. flow rate
7,0 l/min
Detergent flow rate
0,3 l/min
Recoil force of the trigger gun
13 N
Dimensions and weights
Length
411 mm
Width
305 mm
Height
584 mm
Weight, ready to operate with accesso-
ries
13,3 kg
Values determined as per EN 60335-2-79
Hand-arm vibration value
Uncertainty K
3,2
0,8
m/s
2
m/s
2
Sound pressure level L
pA
Uncertainty K
pA
75
3
dB(A)
dB(A)
Sound power level L
WA
+ Uncertainty
K
WA
90 dB(A)
Subject to technical changes.
15
EN
