Water Tanks with outlet connections

When connecting the pressure washer to a water tank with a
suitable tap outlet, first connect the supply hose (not provid-
ed) to the tank outlet, open the tap to allow the water to dis-
place all the air in the hose and then connect to the pressure
washer.

Troubleshooting

Problem

Possible Cause

Corrective Action

Motor refuses to start

Plug not connected

Connect plug

Mains socket faulty

Use another socket

Fuse faulty / blown

Replace fuse

Extension cable damaged

Try without extension cable

Motor protector has activated

Allow to cool for 15 minutes

Frozen

Wait for pump/water supply hose/accessory
to thaw

Motor stops

Fuse faulty / blown

Replace fuse

Wrong mains voltage

Check that mains voltage corresponds to
specifications on the model tag

Motor protector has activated

Allow to cool for 15 minutes

Fuses blow

Fuses incorrectly rated

Change to a mains supply higher than the
pressure washer amp consumption

Motor starts but no pressure

Nozzle partly blocked

Clean nozzle

Motor “sounds” but fails to start

Insufficient power supply

Check that the voltage of the mains power
supply line is the same as that on the plate

Voltage loss due to use of extension cable

Check characteristics of extension cable

Appliance not used for a long period of time Contact your Bosch Service Centre

Problems with TSS (Total Stop System) de-
vice

Contact your Bosch Service Centre

Pressure pulsating

Air in the inlet water supply hose/pump

Allow pressure washer to run with open spray
handle and nozzle at low pressure until regu-
lar working pressure is obtained

Inadequate water supply

Check that the water supply corresponds to
specifications. The minimum specification
for the water supply hose is 1/2" or 13 mm di-
ameter

Water filter blocked

Clean water filter

Water supply hoses squeezed

Straighten out kinked water supply hoses

High pressure hose too long

Remove high pressure extension hose. Retry
(extension hose max. 7 m)

Pressure too low, but steady

Note: Several types of accessory
will normally deliver a lower pres-
sure

Nozzle worn

Change the nozzle

Start/stop valve worn

Activate trigger five times in quick succession

Motor starts up but with restricted
or no working pressure

No water supply

Connect water supply

Water filter clogged up

Clean the water filter

Nozzle clogged up

Clean nozzle

The pressure washer starts irregu-
larly by itself

Pump/ power gun leaky

Contact your Bosch Service Centre

Water leaks from machine

Leaking pump

A slight water leak is permissible; in case of
excessive leak, contact Bosch Service Centre
