SETTING PROCEDURE TO LINK UP WITH THE FRAME UNIT

The remote sensor is designed for easy set up with no wire installation. The following steps are required to be done
in conjunction with the procedure descript in section 6 on “How to install remote
sensor”

1.

Remove the bracket stand.

2.

Unlock two latches in the bottom to release the semiJtransparent jacket.

3.

Slide down the battery door at the rear side.

4.

Insert x2 AAA batteries according to polarity marking on the battery comJ
partment.

5.

The LED blinks slowly to indicate it is set to channel 1 and the user can change it to other channel by pressJ
ing the [CH] key.

6.

The temperature and humidity of the sensor will appear on the selected channel of the Frame unit if it is
linked up with the receiving unit successfully.

7.

Close the battery door and use two latches in the bottom to lock it with the semiJtransparent jacket.
Follow the same procedure (1 to 7) to register other remote sensors.

Note:

For user purchasing more than one remote sensor, he must set the sensors to different channel in the

start up to avoid conflicts.

GETTING STARTED

The RST01928 Color Weather Station was designed for easy set up. For best operation, the following steps are
required to be done in the proper sequence.

a.

Connect the adaptor power plug into the power socket of the Frame unit, and then plug in the power
adaptor into the wall Jack;

Note:

The socketJoutlet shall be installed near the equipment and shall be easily accessible.

b.

Insert the backup battery;

•

Remove the battery door cover on the rear side of the frame unit;

•

Insert x3 AAA size 1.5V alkaline battery as indicate by the polarity;

•

Close the battery door.

Note:

Replace the batteries when the low battery indicator appears on the topJright corner of the front

Lens.

c.

Press the power switch to turn on the Frame unit.
