- 87 -
Appendix
The BIOS Setup menus described in this section may differ from the exact settings for your moth-
erboard. The actual BIOS Setup menu options you will see shall depend on the motherboard you
have and the BIOS version.
5-1-2 Configuring Marvell 88SE9128 SATA Controller
A. Installing SATA hard drive(s) in your computer
Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to available
SATA port on the motherboard. The Marvell 88SE9128 SATA controller controls the eSATA ports on the back
panel. Then connect the power connector from your power supply to the hard drive.
B. Configuring SATA controller and RAID mode in BIOS Setup
Make sure to configure the SATA controller mode correctly in system BIOS Setup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST. In BIOS Setup, go to
Integrated Peripherals
. To enable RAID, make sure
eSATA3 Controller
is enabled. Then set
eSATA3 Ctrl
Mode
to
IDE
or
AHCI
, depending on your requirements (Figure 1). (In AHCI mode, installation of the SATA
AHCI driver is required during Windows XP installation.) Refer to section, "5-1-3," for more details.
Figure 1
Step 2:
Then make sure
eSATA3 Transaction
Mode
is set to
Fw Mode
. To create a RAID array, press <Enter> on
the
eSATA3 RAID Configuration
item to enter the RAID configuration menu. Skip this step if you do not want
to create RAID.
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Integrated Peripherals
eXtreme Hard Drive (XHD)
[Disabled]
PCH SATA Control Mode
[IDE]
SATA Port0-3 Native Mode
[Enabled]
USB Controllers
[Enabled]
USB Legacy Function
[Enabled]
USB Storage Function
[Enabled]
Azalia Codec
[Auto]
Onboard H/W LAN
[Enabled]
SMART LAN
[Press Enter]
Onboard LAN Boot ROM
[Disabled]
R_USB30 Controller
[Enabled]
R_USB30 Turbo
[Disabled]
F_USB30 Controller
[Enabled]
eSATA3 Controller
[Enabled]
eSATA3 Ctrl Mode
[IDE]
eSATA3 Transaction Mode
[Fw Mode]
eSATA3 RAID Configuration
[Press Enter]
SATA3 Firmware Selection
[Auto]
Onboard Serial Port 1
[3F8/IRQ4]
higf
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
