- 49 -
BIOS Setup
Onboard LAN Boot ROM
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
R_USB30 Controller (Back Panel Renesas D720200 USB Controller, USB Connectors
on the Back Panel)
Enables or disables the back panel Renesas D720200 USB controller. (Default: Enabled)
R_USB30 Turbo (Back Panel Renesas D720200 USB Controller, USB Connectors on
the Back Panel)
Enables or disables the Turbo USB mode for the back panel Renesas D720200 USB controller. The
actual performance may vary depending on the number of devices being installed. (Default: Disabled)
F_USB30 Controller (Front Panel Renesas D720200 USB Controller, USB Connectors
on the Front Panel)
Enables or disables the front panel Renesas D720200 USB controller. (Default: Enabled)
eSATA3 Controller (Marvell 88SE9128 Chip, eSATA Connectors on the Back Panel)
Enables or disables the SATA controller integrated in the Marvell 88SE9128 chip. (Default: Enabled)
eSATA3 Ctrl Mode (Marvell 88SE9128 Chip, eSATA Connectors on the Back Panel)
Allows you to decide whether to configure the SATA controller integrated in the Marvell 88SE9128 chip
to AHCI mode.
IDE
Configures the SATA controller to IDE mode. (Default)
AHCI
Configures the SATA controller to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specification that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
eSATA3 Transaction Mode (Marvell 88SE9128 Chip, eSATA Connectors on the Back
Panel)
Allows you to decide whether to enable RAID for the Marvell 88SE9128 SATA controller.
Bypass
Disables RAID.
Fw Mode
Enables RAID. (Default)
Auto
Lets the BIOS configure this setting depending on the hard drives connected.
In case you want to switch to
Fw Mode
from other modes and to be able to enter the
eSATA3 RAID
Configuration
screen, after selecting
Fw Mode
, be sure to save the settings and exit BIOS Setup first
for the settings to take effect.
eSATA3 RAID Configuration (Marvell 88SE9128 Chip, eSATA Connectors on the Back
Panel)
Allows you to configure RAID for the Marvell 88SE9128 SATA controller. Refer to Chapter 5, "Configur-
ing SATA Hard Drive(s)," for instructions on configuring a RAID array.
SATA3 Firmware Selection
Determines whether to automatically update the firmware of the Marvell 88SE9128 chip.
Onchip
Keeps the original firmware version.
Auto
Lets the BIOS automatically update the firmware to the latest version. (Default)
Force
Forces the BIOS to flash the firmware with the same version as the one embedded in
the system BIOS, even if it's not the latest one.
Onboard Serial Port 1
Enables or disables the first serial port and specifies its base I/O address and corresponding interrupt.
Options are: Auto, 3F8/IRQ4 (default), 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Disabled.
