- 51 -
BIOS Setup
2-6 Integrated Peripherals
eXtreme Hard Drive (Intel P55 Chipset)
j
Enables or disables the X.H.D function for the SATA controllers integrated in the Intel P55 Chipset. When
set to
Enabled
, the
PCH SATA Control Mode
item below will be set to
RAID(XHD)
automatically. For
details on using the GIGABYTE X.H.D utility, refer to Chaper 4, "eXtreme Hard Drive (X.H.D)." (Default:
Disabled)
PCH SATA Control Mode (Intel P55 Chipset)
j
Enables or disables RAID for the SATA controllers integrated in the Intel P55 Chipset or configures the
SATA controllers to AHCI mode.
IDE
Disables RAID for the SATA controllers and configures the SATA controllers to IDE
mode. (Default)
RAID(XHD)
Enables RAID for the SATA controllers.
AHCI
Configures the SATA controllers to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specification that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
SATA AHCI Mode (Intel H55 Chipset)
k
Configures the SATA controllers integrated in the Intel H55 Chipset to AHCI mode.
IDE
Disables RAID for the SATA controllers and configures the SATA controllers to IDE
mode. (Default)
AHCI
Configures the SATA controllers to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specification that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Integrated Peripherals
eXtreme Hard Drive (XHD)
j
[Disabled]
PCH SATA Control Mode
j
[IDE]
SATA AHCI Mode
k
[IDE]
SATA Port0-3 Native Mode
[Enabled]
USB Controllers
[Enabled]
USB Legacy Function
[Enabled]
USB Storage Function
[Enabled]
Azalia Codec
[Auto]
Onboard H/W 1394
[Enabled]
Onboard H/W LAN
[Enabled]
Green LAN
[Disabled]
SMART LAN
[Press Enter]
Onboard LAN Boot ROM
[Disabled]
Onboard SATA/IDE Device
[Enabled]
Onboard SATA/IDE Ctrl Mode
[IDE]
Onboard Serial Port 1
[3F8/IRQ4]
higf
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
j
Only for GA-P55M-UD2.
k
Only for GA-P55M-US2.
