- 20 -

Hardware Installation

  DiplayPort

j

(Note 1)(Note 3)



DisplayPort is one of the new generation interface technologies that delivers high quality digital imaging
and  audio,  supporting  bi-directional  audio  transmition.  DisplayPort  can  support  both  DPCP  and  HDCP
content protection mechanisms. Connect the audio/video device that supports DisplayPort to this port. The
DisplayPort  Technology  can  support  a  maximum  resolution  of  2560x1600p  but  the  actual  resolutions  sup-
ported depend on the monitor being used.

Dual Display Configurations for the Onboard Graphics:



The table below shows

 the supported dual display configurations for the onboard graphics ports when



in the BIOS Setup program or when during the POST stage. There is no such limitation in operating sys-



tem environment.

(Note 1)  To use the onboard D-Sub, DVI-D, HDMI, and DisplayPort

j

 ports, you must install an Intel CPU





with integrated graphics.





(Note 2)   The DVI-D port does not support D-Sub connection by adapter.
(Note 3)   You can use only one of the onboard digital graphics ports (e.g. DisplayPort

j

, HDMI, and DVI-D)

for output when in the BIOS Setup program or when during the POST screens.

After installing the DisplayPort device, make sure the default device for sound playback is the Dis-
playPort device. (The item name may differ from operating system. For example, in Windows Vista,
go to Start>Control Panel>Sound>Playback and set the DisplayPort device as the default play-

back device. Refer to the HDMI settings information on the previous page for the configuration

dialog box.)

      Combination     Supported or Not
  DVI-D + D-Sub

Yes

  DVI-D + HDMI

No

  DVI-D + DP

j



No

  HDMI + D-Sub

Yes

  HDMI + DP

j



No

  DP + D-Sub

j



No

Display
Matrix



j

  Only for GA-H55M-UD2H
