- 39 -
BIOS Setup
2-5
Integrated Peripherals
CMOS Setup Utility-Copyright (C) 1984-2007 Award Software
Integrated Peripherals
On-Chip Primary PCI IDE
[Enabled]
On-Chip SATA Mode
[Auto]
x
PATA IDE Set to
Ch.0 Master/Slave
SATA Port 0/2 Set to
Ch.2 Master/Slave
SATA Port 1/3 Set to
Ch.3 Master/Slave
USB Controller
[Enabled]
USB 2.0 Controller
[Enabled]
USB Keyboard Support
[Disabled]
USB Mouse Support
[Disabled]
Legacy USB storage detect
[Enabled]
Azalia Codec
[Auto]
Onboard H/W LAN
[Enabled]
`
SMART LAN
1
[Press Enter]
Onboard LAN Boot ROM
[Disabled]
Onboard Serial Port 1
[3F8/IRQ4]
Onboard Parallel Port
[378/IRQ7]
Parallel Port Mode
[SPP]
x
ECP Mode Use DMA
3
KLJI
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
`
On-Chip Primary PCI IDE
Enables or disables the first integrated IDE controller. (Default: Enabled)
On-Chip SATA Mode
Configures the integrated SATA controller.
Disabled
Disables the integrated SATA controller.
Auto
Lets BIOS set SATA devices to
Combined
or
Enhanced
mode.
If your onboard SATA controller is automatically configured to
Combined
mode, you can manually re-configure it to
Enhanced
mode as needed.
(Default)
Combined
Sets all SATA devices to operate in PATA mode.
Combined
allows a
maximum of 4 ATA devices to be used simultaneously: two PATA devices
plus two SATA devices.
Enhanced
Sets all SATA devices to operate in SATA mode.
Non-Combined
Sets all SATA devices to operate in PATA mode and disables the integrated
IDE controller.
PATA IDE Set to
This item is configurable only if the
On-Chip SATA Mode
is set to
Combined
.
Ch.0 Master/Slave Sets the IDE channels to Ch. 0 Master/Slave. (Default)
Ch.1 Master/Slave Sets the IDE channels to Ch. 1 Master/Slave.
Disabled
Disables the integrated IDE controller when
Non-Combined
is selected.
SATA Port 0/2 Set to
This value is dependent on the
On-Chip SATA Mode
and
PATA IDE Set to
settings.
When
PATA IDE Set to
is configured to
Ch. 1 Master/Slave
, this option will be automatically set
to
Ch. 0 Master/Slave
.
Only for GA-945GCM-S2L.
