Appendix

- 67 -

English

(2)

Configuring SATA controller mode and boot sequence in BIOS Setup

You have to make sure whether the SATA controller is configured correctly in system BIOS Setup and
set BIOS boot sequence for the SATA hard drive(s).

Step 1:
Turn on your computer and press Del to enter BIOS Setup during POST (Power-On Self Test). If you
want to create RAID, set

SATA RAID/AHCI Mode

 under the

Integrated Peripherals

 menu to

RAID

(

Disabled

 by default). Then, set

On-Chip SATA Mode

to

Manual

or

Auto

(default) based on your

own requirements.

Figure 1

The BIOS Setup menus described in this section may not show the exact settings for your
motherboard. The actual BIOS Setup menu options you will see shall depend on the motherboard
you have and the BIOS version.

CMOS Setup Utility-Copyright (C) 1984-2004 Award Software

Integrated Peripherals

On-Chip Primary PCI IDE

[Enabled]

SATA RAID/AHCI Mode

[Disabled]

On-Chip SATA Mode

[Auto]

x PATA IDE Set to

Ch.1 Master/Slave

SATA Port 0/2 Set to

Ch.2 Master/Slave

SATA Port 1/3 Set to

Ch.3 Master/Slave

USB Controller

[Enabled]

USB 2.0 Controller

[Enabled]

USB Keyboard Support

[Disabled]

USB Mouse Support

[Disabled]

Legacy USB storage detect

[Enabled]

Azalia Codec

[Auto]

Onboard H/W 1394

[Enabled]

Onboard H/W LAN

[Enabled]

Onboard LAN Boot ROM

[Disabled]

Onboard Serial Port 1

[3F8/IRQ4]

Onboard Parallel Port

[378/IRQ7]

Parallel Port Mode

[SPP]

x ECP Mode Use DMA

3

: Move

Enter: Select

+/-/PU/PD: Value

F10: Save

ESC: Exit

F1: General Help

F5: Previous Values

F6: Fail-Save Default

F7: Optimized Defaults

Item Help
Menu Level
