28

GW39-008_v01

Outline and parts of the hair clipper

(Fig. A)

1

 Cutting head

2

 Cutting length adjustment knob

3

 On/OFF switch

4

 LCD display

5

 Battery rechargeable

6

 Loading socket

7

 Attachments (4-6; 10-12; 16-18; 22-24; 28-30 mm)

8

 Power supply

9

 Cleaning brush

10

 Lubricating oil for blades

11

 Comb

12

 Scissors

LCD display

A

 percentage charging level indicator

B

 graphical battery charging level indicator

C

 mains supply connection indicator

Handling and operation of hair clipper

OPERATION WITH POWER SUPPLY ADAPTOR

At  irst  insert  the  adaptor  plug  into  the  device  and  then

insert the adapter plug into the mains supply outlet (230 V).

In mains supplied mode the device is ready for use.

LOADING ACCUMULATORS AND CORDLESS

OPERATION

Load  the  device  minimum  16h  before  irst  usage  and

when 2–3 next loadings.

Make sure the appliance is switched off before charging.

●

The process of battery (installed in the trimmer) charging

●

lasts approximately 2 hours.

The  trimmer  can  work  approx.  60  minutes  with  fully

●

charged batteries.

Insert the ending of the power supply to the trimmer

–

charging socket

(6)

,

Insert  the  plug  of  the  power  supply  in  the  mains

–

supply  outlet.  The  percentage  and  graphical

charging level indicators show the charging process

advancement (lashing).

When  the  battery  is  fully  charged,  the  LCD  display

●

(4)

indicates 100 and it is highlighted in

blue

.

When the battery charging level decreases below 20, the

●

graphical  battery  charging  level  indicator

(B)

  and  mains

supply connection indicator

(C)

 start lashing.

When  the  battery  is  almost  empty,  the  display  colour

●

changes into

red

. Connect the trimmer to the mains supply.

The  hair  clipper  accumulator  obtains  optimum  power

●

after  three  cycles  of  loading  and  unloading.  Ten  hours

is  enough  for  next  loading.  In  order  to  provide  long  life

of  accumulators,  they  should  be  completely  unloaded

before loading.

COMB ATTACHMENTS INSERTING / REPLACING

Select the attachment according to the length of cutting.

●

Insert appropriate attachment into the sides of the device.

●

The  protrusions  shall  be  locked  inside  small  holes  (see

the igure beside) on left and right sides.

Replace  one  attachment  removing  it  and  inserting

●

another as described above.

In order to remove an attachment bent one side of assembled

attachment gently and then move it up.

Move the cutting length adjustment knob

●

(2)

, to increase/

reduce  the  hair  cutting  length. The  possible  hair  cutting

length is indicated on each attachment (i.e. 4–6 mm).

USING THE TRIMMER FOR HEAR CUTTING

Cut  the  hair  for  demanded  length  in  stages,  start  form

bigger length.

Insert an appropriate attachment

●

(7)

.

Set  the  desired  length  of  hair/beard  cutting  with  cutting

●

length adjustment knob

(2)

.

Start up the hair clipper pressing in ON/OFF button

●

(3)

.

Cut only small areas.

●

Move the clipper slowly along hair.

●

Hold the device so, that the comb attachment is laid lat.

●

Always  start  the  cutting  from  the  neck  upwards  or  from

●

the forehead and temples upwards  to the top of head.

CUTTING HAIR WITHOUT ATTACHMENT

WARNING:  The  cutting  head  (1)  is  very  sharp.  Injury

hazard!

Cutting  without  attachment  makes  possible  to  trim  the

contour, hair line and whiskers as well as neck shaving.

Turn  the  device  so,  that  the  back  part  was  directed

●

upwards.

Place  the  edge  of  the  cutting  head

●

(1)

  without  comb

attachment on desired length of bristle hairline.

Move down the clipper in operation.

●

Cleaning and maintenance

Start the device pressing in ON/OFF button

●

(3)

.

Always switch off the hair clipper and unplug the adaptor

●

from  the  mains  supply  outlet  before  cleaning  and

maintenance.

Remove the comb attachment from the hair clipper.

●

In  order  to  remove  cutting  head  press  the  cutting  head

●

blade

(1)

 forward with your thumb, in order to release it

from the frame

(Fig. C)

.

If  necessary,  rinse  the  plastic  comb  attachments  under

●

running water, and then dry them thoroughly.

Remove  the  remains  of  hair  from  the  cutting  head

●

(1)

with attached cleaning brush

(VII)

.

Insert  the  protrusion  of  cutting  head

●

(1)

  back  into  the

locking hole in the frame of cutting head.

Press  gently  the  cutting  head

●

(1)

  in,  until  you  hear

a clicking sound of locking.
