Soundmax SM-CMD5003 - Инструкция по эксплуатации - Страница 18

18

Clock setting: A touchable keyboard is displayed. Input the current time and touch OK to confirm.

DVD page

OSD lang: Select on-screen display language.

Subtitle lang: Select a DVD subtitle language.

Audio lang: select a language of the DVD audio.

DVD menu lang: Select a language of the DVD menu.

Password: In order to make the Rating feature work, the password mode must be turned on. If you want

to  set  the  ratings  limit,  you  will  need  to  enter  the  default  password,  which  is  0000,  then  press  ENTER  to

confirm. To change the password, enter the Password change submenu. If you change the password, the

default password 0000 will be void.

Rating: The Rating control level is for parents to control playing content and protect your children from

violence and erotic. The disc, the level of which is higher than the setting level can not be played.

TV  shape:  Select  4:3/PS  (the  wide-screen  image  shows  on  the  full  screen,  but  some  part  is  cut  off,

4:3/LB  (the  wide-screen  image  shows  and  black  bars  appear  on  the  top  and  bottom  of  screen,  Wide

(wide-screen image is shown).

NTSC/PAL: Select color system NTSC or PAL.

Default: Reset to the initial factory settings.

System info page

In this menu you can see the current version information. Besides, calibration function is available:

Calibration: “Carefully press and hold stylus on the center of the target longer than 1 second” is displayed.

Touch and hold the red cross in each position until it moves to a different position. After repeating it 4 times,

the calibration of the screen is complete. The calibration procedure is useful when some malfunction occur

with the touch screen and it needs adjustment.
