Kenwood KDC-2027SA(SG) - Инструкция по эксплуатации - Страница 7

1

Select the source for adjustment

Press the [SRC] button.

2

Enter Audio Control mode

Press the [AUD] button for at least 1 second.

3

Select the Audio item for adjustment

Press the [FM] or [AM] button.

Each time the button is pressed the items that can be adjusted
switch as shown below.

4

Adjust the Audio item

Press the [

4

] or [

¢

] button.

Adjustment Item

Display

Range

Bass level

"BAS"

–8 — +8

Middle level

"MID"

–8 — +8

Treble level

"TRE"

–8 — +8

Balance

"BL"

Left 15 — Right 15

Fader

"FD"

Rear 15 — Front 15

5

Exit Audio Control mode

Press the [AUD] button.

Audio Control

You can recall the best sound setting preset for different types of
the music.

1

Select the source to set

Press the [SRC] button.

2

Select the Sound type

Press the [Q] button.

Each time the button is pressed the sound setting switches.

Sound setting

Display

Flat

"FLAT"

Rock

"ROCK"

Top 40

"TP40"

Pops

"POPS"

Jazz

"JAZZ"

Easy

"EASY"

• Each setting value is changed with the <Speaker setting> (page

8).
First, select the speaker type with the Speaker setting.

• When the System Q setting is changed, the Bass, Middle, and

Treble set in audio control replace the System Q values.

System Q

Compensating for low and high tones during low volume.

Press the [LOUD] button for at least 1 second.

Each time the button is pressed for at least 1 second the
Loudness turns ON or OFF.
When it’s ON, "LOUD" indicator is ON.

Loudness

— 7 —
