6

ENGLISH

Control panel —

KD-SHX851

Parts identification

1

T/P (traffic programme/programme
type) button

•  Turns on/off TA (Traffic Announcement)

Standby Reception (see page 15) if pressed.

•  Displays the PTY operation screen (see

page 13) if pressed and held.

2

0

(eject)/

(angle) button

•  Ejects the disc if pressed.
•  Adjusts the control panel angle if pressed

repeatedly after held once.

3

DISP (display) button

Changes the information shown on the

display.

4

 (standby/on/attenuator)/

OK

button

•  Turns on and off the power and also

attenuates the sound.

•  Confirms the selection while operating

the menus.

Volume control dial

Adjusts the volume level.

5

SOURCE button

 Selects the source.

6

4

/

¢

 (

/

) buttons

•  For FM/AM and DAB:

 Searches for

stations (or ensembles) if pressed, or skips
frequencies after pressed and held.

•  For discs or an SD card:

 Changes the

tracks if pressed, or fast-forwards or
reverses the track if pressed and held.

•

For menu operations:

 Selects the menu

items/values.

7

Remote sensor

DO NOT expose the remote sensor on
the control panel to strong light (direct
sunlight or artificial lighting).

8

Color display window

9

BAND/BACK button
•  For FM/AM and DAB:

 Selects the band.

•

For menu operations:

 Goes back to the

previous screen.

p

PICT (picture) button

Displays the PICT menu.

q

MENU button

Displays the MENU screen.

w

Reset button

e

5

 (up) /

∞

 (down) buttons

• For FM/AM:

Displays Preset Station List

if pressed and held.

• For DAB:

 Changes the services if

pressed, or displays Preset Service List if
pressed and held.

•  For MP3/WMA discs or an SD card:

Changes the folders if pressed, or displays
Disc List (only for “CD-CH”) or Folder
List if pressed and held.

•

For menu operations:

 Selects the menu

items/values.

r

 (control panel release) button

MENU

PICT

SOURCE

DISP

T/P

BACK

BAND
