14

Operation

off.

•  PI SOUND/MUTE: Choose either PI sound

or PI mute. PI sound refers to the reception
noise when the AF function tries to scan
alternative frequency.

•  RETUNE S/L: RETUNE refers to the time

period the unit allows for radio scan when
reception is interrupted. SHORT represents
a time period of 30 seconds and LONG
represents a time period of 90 seconds.

•  MASK DPI/ALL: During MASK DPI mode,

the unit will mask only the AF which has
different PI, this is the default mode; during
MASK ALL mode, the unit will mask the AF
which has different PI and no RDS signal with
high field strength.

TV operations

TV and audio system

•  Press repeatedly SYSTEM button on the

RC or BND/NP button on the panel to select
one of the available TV systems.

•  Press repeatedly AUDIO button on the RC

to select one of the available sound systems.

Search channels

Press AUDIO TYPE/APS button on the panel

or AMS button on the RC to automatically
search and save all available TV channels.
Press and hold PREVIOUS/NEXT buttons on
the panel or RC to adjust the current frequency
step by step.

Save channels

•  When a channel is found, press and

hold a number button on the RC. The current
channel will be saved in the corresponding
number position. To call a saved station, press
a number button on the RC.

•  Press PREVIOUS/NEXT buttons on the

RC or panel to go to previous or next saved
channel.

Disc/USB/SD/MMC operations

Insert/Eject disc

•  Open the front panel and insert a disc into

the disc slot with label side up. The disc will be
automatically loaded into the unit. The first file
in the root folder will be played. Close the front
panel.

•  Open the front panel and press EJECT

button to eject the disc from the slot. If the disc
is not removed from the slot within several
seconds, it will be automatically loaded into
the slot again. When the disc is ejected and
removed, the unit will automatically switch to
another mode.

  Manufacturer guarantees regular

playback of licensed discs only. Some AVI
files cannot be played due to their parameters
and recording conditions. Video files more
than 2 Gb having AVI extension can be played
partially.

MP3/DivX/JPEG file playback

When you insert a storage containing MP3/

DivX/JPEG files, the screen will show following
interface:

1

2
3

4

1. Music/Photo/Video
2. Playback status
3. Track number/track name/folder name

(depending on the format)

4. Current track playback elapsed/remaining

time
