Hyundai Electronics H-CMD4029 - Инструкция по эксплуатации - Страница 10

10

Operation

Setting other characteristics

•  Press MENU button to enter the setting

mode.

•  In the menu press UP/DOWN cursor

buttons on the RC or rotate VOLUME knob
on the panel to select a setting page. Press
ENTER button or LEFT cursor button on the
RC or press OK button on the panel to go to
the selected page.

•  In the selected page press UP/DOWN

cursor buttons on the RC or rotate VOLUME
knob on the panel to select a setting. Press
ENTER button on the RC or OK button on the
panel to adjust the selected setting.

•  After you performed the adjustment, press

MENU button to return to the setting page.
Press MENU button again to quit setting menu.

•  Following setting pages are available:

AUDIO (available in Radio, Disc, USB and

Card modes):

Bass: support 10 levels. Default level is 0.
Treble:  support 10 levels. Default level is 0.
Balance: support 10 levels for each left and

right channel. Default is left equal to right.

Fader:  support 10 levels for each front and

rear channel. Default is front equal to rear.

EQ: DSP OFF => FLAT => CLASSICS =>

POP => ROCK.

PICTURE (available in Disc, USB and Card

mode):

Red: Adjust level of red color. Support 50

levels. Default level is 25.

Green: Adjust level of green color. Support

50 levels. Default level is 25.

Blue: Adjust level of blue color. Support 50

levels. Default level is 25.

Brightness: Support 50 levels. Default level

is 25.

Contrast: Support 50 levels. Default level is 25.
Sharpness: Support 15 levels. Default level

is 10.

Screen: Adjust screen size: 16:9 - 4:3 - FULL.
Color reset: Resume color default status.

(Select YES or NO by cursor buttons, and
press OK or ENTER button).

General operations

Turning on/off

Press any button (except OPEN button) to

turn on the unit. Press and hold PWR/MUTE
button on the panel or POWER button on the
RC to switch the unit off.

  After the unit is off, the volume level

and radio current settings will be memorized,
and when you turn the unit on it will resume
the stored status you previously set. To protect
your ear from too loud sound, the unit volume
level will turn to 20 automatically when you
turn the unit on if currect volume level setting is
above 20 when your turn the unit off.

Volume control

Rotate VOLUME regulator or press VOL+/

VOL- buttons on the RC to adjust the volume
level.

Mute function

Press PWR/MUTE button on the panel or

MUTE button on the RC to turn the sound off.
Press it again or adjust the volume to turn the
sound on.

Setting the sound characteristics

•  Press SEL button on the RC to enter the

audio setting menu consisting of following items:
Bass =>Treble => Balance => Fader => EQ.

•  Press UP/DOWN cursor buttons on the

RC or rotate VOLUME regulator on the panel
to select a setting. Press ENTER button on the
RC or OK button on the panel to confrim the
selected setting. Press LEFT/RIGHT cursor
buttons on the RC or rotate VOLUME regulator
on the panel to adjust the setting.

•  Press SEL button again to confirm and

return to current mode.

  If turning off the power all the settings of

each mode will be saved. If turning off the ACC
power all the settings will reset to default values.
If you don’t adjust setting within several seconds
after selecting the desired setting, the unit will
automatically return to the current mode.
