Operation

Operation

General operations

Touch screen

Due to the touch screen, you can fulfill most

functions not only by pressing buttons but also
by touching the options you need.

Turning the unit on/off

Press any button (except EJECT button) to

switch the unit on. Press and hold POWER
button on the panel or PWR button on the RC
to turn off the power.

Reset the unit

Operating the unit for the first time or after

replacing the car battery, you must reset the
unit. Press reset button on the unit with a
pointed object (such as a ballpoint pen) to set
the unit to initial state.

  When some errors occur on the display,

you can also press reset button to resume to
normal, and it will erase the clock setting and
some memorized functions.

Volume control

Press VOL+/VOL- buttons on the RC or on

the unit to increase/decrease the sound level.

Setting the sound characteristics

Press SEL button to open the following menu:

1

2

3 4

1. Setting list. Touch a setting to select its

adjustment.

2. Adjustment buttons. Touch them to adjust

corresponding setting.

3. Page selection buttons. Touch to select a

menu page.

4. Return button. Touch to return to previous

menu level.

Following settings are available for

adjustment:

Page 1
•  Equalizer: Select Flat, Classic, Pop, Rock

or DSP OFF equalizer mode.

•  TA volume: Adjust the volume level for TA

radio service.

Page 2
•  Bass: Adjust the low-frequency level.
•  Treble: Adjust the high-frequency level.
•  Balance: Adjust the balance between left

and right channels.

•  Fader: Adjust the balance between front

and left channels.

Page 3
•  Beep: Select ALL (beep is heard at any

button pressing), 2ND (beep is heard when a
button is pressed and held) or OFF (no beep).

•  Loud: Selecting loudness ON will

emphasize the low frequency output.

•  Subwoofer: set the subwoofer on or off.

  You can also press

/

 buttons on

the RC to select menu pages; press UP/DOWN
cursor buttons to select a setting, press LEFT/
RIGHT buttons to adjust the setting.

Mute function

Press MUTE button on the RC or PWR

button on the unit to turn off the sound. Press
the button again or adjust volume to resume
the sound output.

Mode selection

•  Repeatedly press MODE button on the RC

or on the panel to select an operation mode.

•  In any mode press MENU button to display

the Main menu consisting of two pages:
