General information

The display
shows an
error message
(ERROR 1 – 11)
one time.

Possible disc error.

Reset the unit by pressing RESET hole.
Ensure the disc is inserted correctly
into the slot.
Clean or change the disc.

The display
shows an
error message
(ERROR 1 – 11)
repeatedly.

Unit operation error.

Turn to a service center.

Specifications

General

Power supply

12 V DC

Current consumption

max. 10 A

Maximum power output

4 x 50 W

Fuse

1A & 10A

Dimensions (L x W x H)/Weight

178 x 51 x 178 mm/1.5 kg

Temperature range

-20

0

C - +60

0

C

ESP

40 sec. for CD, 120 sec. for MP3

Mounting angle

0 - +/-30

0

FM stereo radio

Frequency range

87.5 - 108.0 MHz

Presettable stations

18

Stereo separation

35 dB (1 kHz)

MW Section

Frequency range

522 kHz-1620 kHz

Presettable stations

12

Usable sensitivity

30 dB

Disc player

Disc support

СD/CD-R/CD-RW/USB/SD/MMC

Fromat support

CDDA/MP3

Frequency characteristics

20-100 Hz

≤

 5 dB

10-20 kHz

≤

 5 dB

Signal to noise CD

50 dB (1kHz)

Line output

2 channel RCA line-out (2 V)

Specifications are subject to change without notice. Dimensions are approximate.
