10

Operation

your desired radio band during Radio mode:
FM1, FM2, FM3, AM1 (MW1), AM2 (MW2).
In each set of the bands you can store up to 6
preset stations, making total 30 preset memory
stations.

Auto/Manual tuning

Press and hold PREVIOUS/NEXT buttons

to display MANU TUNE. Now you can press
these buttons repeatedly to adjust the needed
frequency manually.

To adjust the needed frequency

automatically, press PREVIOUS/NEXT
buttons. The radio will seek to the next down or
up strong and clear frequency station. Repeat
this action to seek for other desired stations.

Programming tuner stations

There are six numbered preset buttons,

under which you can store and recall stations
for each band. Select the needed station,
then press and hold a preset button. The
station will be saved in the memory under
the corresponding number. To recall a stored
station, press the corresponding preset button.

Automatic store/preset scan

Automatic store
Press and hold F/PS button. The radio will

automatically store the 6 strongest available
stations to the 6 preset memories of the 3 FM or
2 MW bands (depending on which is current).
To stop auto store, press this button again.

Preset scan
Press F/PS button, the receiver will scan the

saved stations in the current band.

Mono/Stereo control

(in FM radio mode)

Press SEL button until the display shows

STEREO (MONO). Turn VOLUME knob to
switch between stereo reception or mono
reception.

Improvement of reception of distant stations

can be done by selecting mono mode, which
may cut down some reception noise.

Local radio station search

Press SEL button to choose LOCAL (DX).

When the LOCAL function is on, the local
stations (stations with weak radio signal) can
be played. When the DX function is on both
local and distant stations (stations with strong
radio signal) can be played.

RDS function

RDS (Radio Data System) service availability

varies with areas. Please understand if RDS
service is not available in you area, the
following service is not available, either.

AF (Alternative Frequencies)

function

Press AF button on the panel to turn the AF

function on or off.

When the radio signal strength is poor,

enabling the AF function will allow the unit to
automatically search another station with the
same PI (Program Identification) as the current
station but with a stronger signal, so that
you do not have to retune the stations when
driving between different transmitter coverage
areas. When AF symbol is on, it means RDS
information is received; when AF symbol is
flashing, it means RDS information is not yet
received.

PS (Program Service name): the name of

station will be display instead of frequency.

If RDS service is not available in your area,

turn off the AF mode. Default setting is ON.

TA (Traffic Alarm) function

Press TA button to turn TA function on or off.
In TA mode traffic program will be

automatically searched, until the program is
received. When traffic announcement is received
the unit will temporarily switch to the tuner mode
(regardless of the current mode) and begin
broadcasting the announcement. After the
traffic announcement is over, it will return to the
previous mode and volume level. To interrupt
traffic announcement press TAbutton shortly; it
will not switch off the TA mode.
