13

Operation

1. Press MENU button and choose the

“setting“ option.

2. Rotate the VOLUME knob on the front

panel or press the UP/DOWN cursor buttons or
VOL+/-buttons on the RC to select the option
you want to adjust.

3. Press the VOLUME knob on the front

panel repeatedly to set the value you want
except setting the Date and Time. When
setting the Date, press the VOLUME knob on
the front panel repeatedly to select the YEAR/
MONTH/DAY, rotate the VOLUME knob to
set the needed value. When setting the Time,
press the VOLUME knob on the front panel
repeatedly to select the HOUR/MINUTE, rotate
it to set the needed value.

General setup page

Language: Change the OSD language

between English and Russian.

Date: Set the current date by turning the

volume knob and pressing it for confirmation.

Clock mode: 12/24 hours.
Time: Set the current time by turning the

volume knob and pressing it for confirmation.

Keytone: Turn on/off the sound when

pressing buttons.

Area: select your region:  Europe/South

USA/East Europe

Output: PAL/NTSC

Accessories

1.  Front panel

1 pc

2.  Protective case

1 pc

3.  ISO adaptor set

1 pc

4.  Remote controller

1 pc

5.  Mounting parts:
     Nut 5 mm

1 pc

     Spring washer

1 pc

     Plain washer

1 pc

     Bolt

1 pc

     Screw 5x6

4 pcs

     Screw 5x20

1 pc

     Metal strap

1 pc

     Release key

2 pcs

     Mounting collar

1 pc

     Trim frame

1 pc

     Rubber cushion

1 pc

6.  Instruction manual

1 pc

7.  Warranty card

1 pc

8.  Consumer information

1 pc

Cleaning the unit body

Wipe with a soft cloth. If the cabinet is very

dampen (not dropping wet) the cloth with a weak
solution of soapy water, and then wipe clean.
