Hyundai Electronics H-CCR8189M - Инструкция по эксплуатации - Страница 11

11

Operation

AF (Alternative Frequencies)

function

Press MUSIC/AF button on the RC or press

and hold   button on the panel to turn on AF
function. If the AF function is on, the display will
show “AF”.

When the radio signal strength is poor,

enabling the AF function will allow the unit to
automatically search another station with the
same PI (Program Identification) as the current
station but with stronger signal strength, so that
you do not have to retune the stations when
driving between different transmitter coverage
areas. When AF symbol is on, it means RDS
information is received; when AF symbol is
flashing, it means RDS information is not yet
received. If RDS service is not available in your
area, turn off the AF mode.

TA (Travel Announcement) / TP

(Travel Program Identification)

Enable or disable TA mode by pressing

and holding MOVIE/TA button on the RC or
button on the panel. Default setting is OFF.

When TA function is activated, it will search

the station with TA information automatically.
If there is no TA information, it will search the
station with TP information automatically, if
there is no TP information either, it will return to
the previous station after searching.

When receiving the station with TP

information but without TA information,
TP icon is on and TA icon keeps blinking;
when receiving the station with TP and TA
information, both TP and TA icons are on.

When playing in other mode and TA

information is received, it will change to the
radio mode automatically. After playing over, it
will return to the previous mode.

PTY (Program Type) (for FM radio)

This radio will allow you to select the type of

program required, and will search for a station
broadcasting that type of program.

Press and hold PHOTO/PTY button on

the RC or   button on the panel to show the
various program type lists. Rotate the volume
knob or press VOL+/- buttons on the RC to
select the needed program type.

When PTY is selected, the radio starts to

search corresponding PTY information, and
stops if the corresponding PTY information
is detected. If no buttons are pressed within
several seconds, previously selected PTY is
searched. During 1 loop, if desired PTY is not
found, the unit will return to previous mode.
Press and hold PHOTO/PTY button on the RC
or   button on the panel to switch the PTY
function off.

USB/SD/MMC operations

USB/SD/MMC notes

USB format supports 2.0. Capacity: up to

32 Gb.

For correct and satisfactory operation,

licensed SD/MMC memory cards of famous
brands should be used with this unit. Avoid
using memory cards of unknown brands.
Capacity: up to 32 Gb.

According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.

Warning: usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

Inserting an SD/MMC card/USB device

Open the front panel and insert an SD/

MMC memory card into the card slot. Open the
USB slot cover on the front panel and insert
