Operation

14

RETUNE S/L - SHORT/LONG
“RETUNE” refers to the time period

the unit allows for radio scan when
reception is interrupted. “S” represents
a long time period, and “L” represents
a short time period.

USB/SD/MMC operations

Connecting a USB-device/

Memory card

Insert a USB device into the USB

port of this unit. Or detach the front
panel and insert an SD/MMC memory
card until a click into the memory card
slot. To remove the card, press it until
a click, then pull to remove.

  USB/SD/MMC supported

capacity: up to 16 Gb.

For correct and satisfactory

operation, licensed SD/MMC memory
cards of famous brands should
be used with this unit. Avoid using
memory cards of unknown brands.
Some models of USB devices cannot
be supported by this unit due to
incompatibility.

According to the USB 1.1/2.0

Standard, usage of a USB device with
power current consumption exceeding
500 mA is not recommended without
supplementary power supply. Failure
to use supplementary power for
connected USB drives with power
consumption exceeding this value
as well as defective USB drives may
cause mechanical or thermal changes
of elements of the unit as well as failure
of internal elements of USB port. Such
damages are not warrantee cases.

  Usage of external USB drives

containing BIN files in the root
directory may cause malfunction of
the unit or damage to the software.

Playback

When a USB or a memory card is

first connected, playback will begin
automatically.

Depending on the number of files

and folders, the device may take
several seconds to begin playback. If
no supported audio files are detected,
“USB” or “SD” will be displayed.

Track select

•  Press

 button to skip to the

beginning of the next track. Press

button to skips to the previous track.

•  Press F/PS button on the panel or

APS button on the RC; track number
will blink on the display. Rotate
VOLUME knob or press VOL+/VOL-
buttons on the RC to select the track
number. Press SELECT button on
the panel or SEL button on the RC to
confirm your selection.

Folder select

Press 5/ - button to select the

previous folder. Press 6/ + button to
select the next folder.

Fast forward/rewind

Press and hold

 or

 button

to rewind or fast forward the current
track.

Pause

Press 1/

 button to temporarily

stop file playback. Press it again to
resume playback.

Intro playback
