ENGLISH
en
11
operation. Press the trigger switch (12) again to
stop the machine.
In continuous operation, the machine
continues running if it is forced out of your
hands. Therefore always hold the machine with
both hands using the handle provided, stand
securely and concentrate.
Clean the machine regularly.
This includes
vacuum cleaning the ventilation louvres on the
motor.
Clean the saw blade clamping fixture regularly and
thoroughly by blowing with compressed air.
If necessary, clean the openings behind the saw
blade support roller (2).
Apply a drop of oil to the saw blade support roller (2)
from time to time.
Plunging
The jigsaw blade can plunge into workpieces made
from thin, soft materials without the necessity of
drilling a hole beforehand. Only use short saw
blades. Only at 0° angle setting.
See illustration on page 2. Set the adjustment lever
(6) to the "0" position (pendulum motion is
deactivated). Position the jigsaw with the front edge
of the footplate (5) on the workpiece. Hold the
operating jigsaw firmly and guide slowly
downwards. Once the saw blade has penetrated
the workpiece, the pendulum motion can be
activated.
In thicker workpieces, a hole for inserting the saw
blade must be drilled first.
Use only genuine Metabo accessories.
Use only accessories which fulfil the requirements
and specifications listed in these operating
instructions.
Fit accessories securely. If the machine is operated
in a holder: Secure the machine well. Loss of control
can cause personal injury.
See page 4.
A Circular-cutting and parallel guide
B Protective plate (prevents workpieces with
sensitive surfaces from becoming scratched)
10.1 Attaching the circular-cutting and
parallel guide
For sawing circles (dia. 100 - 360 mm) and making
cuts parallel with edges (max. 210 mm).
Attach circular guide
(see Fig. I)
- Slide the rod on the circular-cutting and parallel
guide sideways into the footplate (centre point (c)
faces downwards).
- Set the desired radius (d).
- Tighten screw (b).
Attach parallel guide
(see Fig. II)
- Slide the rod on the circular cutting and parallel
guide sideways into the footplate
(the centre point (c) faces upwards).
- Set the dimension (e)
- Tighten screw (b).
In order to minimise saw blade drifting, we
recommend using extra-thick saw blades:
6.23694
,
6.23679, 6.23685
See www.metabo.com or the catalogue for a
complete range of accessories.
Repairs to electrical tools must ONLY be
carried out by qualified electricians!
Contact your local Metabo representative if you
have Metabo power tools requiring repairs. See
www.metabo.com for addresses.
You can download a list of spare parts from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Only for EU countries: Never dispose of
power tools in your household waste! Used
power tools must be collected separately and
handed in for environmentally compatible recycling
in accordance with European Directive 2002/96/EC
on waste electrical and electronic equipment and its
implementation in national legal systems.
Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
M
= Torque
T
1
= Maximum material thickness in wood
T
2
= Maximum material thickness in non-
ferrous metals
T
3
= Maximum material thickness in sheet
steel
n
0
= Stroke rate at idle speed
P
1
= Rated input power
P
2
= Power output
m
= Weight without mains cable
Measured values determined in conformity with
EN 60745.
Machine in protection class II
~
AC Power
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
Emission values
These values make it possible to assess the
emissions from the power tool and to compare
different power tools. The actual load may be higher
or lower depending on the operating conditions, the
condition of the power tool or the accessories.
8. Cleaning, Maintenance
9. Tips and Tricks
10. Accessories
11. Repairs
12. Environmental Protection
13. Technical Data
