15

Cut at a uniform rate, pay attention to avoid overloading the jigsaw.
Excessive pressure applied on the blade will suppress pendulum
action and will affect cutting efficiency unfavourably. Decrease or
switch off the pendulum action completely when cutting along
gently curved line.

When the footplate does not rest on the processed material with

its whole surface but is lifted above, there is danger of kick back
or breaking the blade.

CUTTING A HOLE IN MATERIAL

•

Make a hole in processed material with 10 mm diameter.

•

Put blade into the hole and start cutting from that spot.

METAL CUTTING / TYPES OF BLADES

Use appropriate blades with more teeth for cutting of metal.

For metal cutting use appropriate lubricant (e.g. cutting oil). Metal
cutting without lubrication leads to rapid wear of blade. The below
table gives the best choices for blade type:

Teeth per
inch

Blade
length

Application range

24

80 mm

Soft steel, non-ferrous metals

14

Non-ferrous metals, plastics

9

Wood, plywood:

•

Use only appropriate and sharp blades.

•

Do not use blades with damaged shank.

•

Use appropriate blade types.

OPERATION AND MAINTENANCE

Remove the battery from the device before commencing
any activities related to installation, adjustment, repair or
maintenance.

MAINTENANCE AND STORAGE

•

Cleaning the device after each use is recommended.

•

Do not use water or any other liquid for cleaning.

•

Clean the tool with a dry cloth or blow through with compressed
air at low pressure.

•

Do not use any cleaning agents or solvents, they may damage
plastic parts.

•

Clean ventilation holes in the motor casing regularly to prevent
device overheating. Do not clean ventilation holes by inserting
sharp objects there, such as screwdrivers and other similar objects.

•

Regular lubrication of guiding roller is recommended. A drop of oil
applied in this spot will prolong lifetime of the roller.

•

In case of excessive commutator sparking, have the technical
condition of carbon brushes of the motor checked by a qualified
person.

•

Always store the tool in a dry place, beyond reach of children.

•

Store the device with the battery removed.

All defects should be repaired by ser vice workshop authorized
by the manufacturer.

TECHNICAL PARAMETERS

R AT E D  PA R A M E T E R S

Cordless Jigsaw

Parameter

Value

Battery voltage

18 V DC

Blade stroke cycles (without load)

0-2400 spm

Maximum thickness of cut
material

Wood

80 mm

Metal

10 mm

Blade stroke length

25 mm

Protection class

III

Weight 1,700

kg

Year of production

2017

Graphite Energy+ System Battery

Parameter

Value

Battery

58G001

58G004

Battery voltage

18 V DC

18 V DC

Battery type

Li-Ion

Li-Ion

Battery capacity

2000 mAh

4000 mAh

Ambient temperature range

4

0

C – 40

0

C

4

0

C – 40

0

C

Charging time for charger 58G002

1 h

2 h

Weight

0,400 kg

0,650 kg

Year of production

2017

2017

Graphite Energy+ System Charger

Parameter

Value

Charger type

58G002

Supply voltage

230 V AC

Power supply frequency

50 Hz

Charging voltage

22 V DC

Max. charging current

2300 mA

Ambient temperature range

4

0

C – 40

0

C

Charging time of the battery 58G001

1 h

Charging time of the battery 58G004

2 h

Protection class

II

Weight

0,300 kg

Year of production

2017

N O I S E  L E V E L  A N D V I B R AT I O N  PA R A M E T E R S

Noise and vibration information

Parameters of produced noise level, such as sound pressure level
Lp

A

 and sound power level Lw

A

 with measurement uncer tainty K

are specified below in this manual, in compliance with EN 60745.
Vibration values a

h

 and measurement uncer tainty K are

determined in accordance with EN 60745 and specified below.
Vibration level specified below in this manual was measured in
accordance with measurement procedure defined in EN 60745
and can be used to compare power tools. It can also be used for
initial assessment of exposure to vibrations.
Specified vibration level is representative for main applications
of the power tool. Vibration level may change if the power tool is
used for other purposes, with different working tools or will not
be maintained properly. The abovementioned factors may lead
to higher exposure to vibrations during whole working time.
To precisely define exposure to vibrations, include periods when
the power tool is switched off and when it is switched on but
not used for working. This way total exposure to vibrations may
be significantly lower. Use additional safety measures to protect
the user against results of exposure to vibrations, such as: power
tool and working tool maintenance, proper hand temperature
conditions, good work organisation.
