12

G

Maintenance

Storage

z

Make sure to store the battery-powered shears out of the reach
of children.

z

Always attach the blade guard for transport and storage.

z

Always recharge the lithium-ion battery prior to any prolonged
period of non-use, i.e. before storing the shears away in winter.

z

Store the battery-powered shears in a dry and frost-free location.

General instructions

1

Caution! Counterrotating blade

Before carrying out any maintenance or cleaning work:

z

Never actuate the switches

 (1) (2).

z

Do not touch the moving blade.

z

Drive repairs may only be carried out by a WOLF-Garten
service facility!

Cleaning

z

Clean the battery-powered shears after every use with a dry
cloth.  If necessary, use a brush to remove persistent dirt.

z

Clean and lubricate the gearbox at the end of the gardening sea-
son (see "Cleaning or replacing the blade").

z

Never clean the battery-powered shears with a water jet.

Cleaning or replacing the blade

3

Blunt blades should not be resharpened but replaced.

1. Remove wheels

Carefully pull the wheels apart until they come off the
rechargeable shears. Then remove the wheels from below.

2. Remove skid

Lever the retainer (1) upwards and then remove the skid from
the rear (2).

3. Replace cutting head

Remove the cutting head from the rechargeable shears. Lubri-
cate the plastic ring of the cutter with the lubrication tube (Part of
the „replacement blade package“)

 provided, clean the visible

area of the drive, and lubricate this as well with the lubricant pro-
vided. Turn the new cutter head with the plastic ring in the direc-
tion of the drive.

1

Note for shear blades (Accu 8 EM, Accu 10 EM):

Please ensure that the blades are staggered in relationship
to each other

 (1).

1

Note for shrub blades (Accu BS EM):

Position the plastic ring in such a way that it is precisely
placed over the eccentric tappet

.

Push the blade diagonally under the projections

 (2) and

position it in the recharageble shears so that the drill holes of
the blade

 sit above the bolts of the rechargeable shears.

4. Fastening the skid

Push the skid far enough over the rechargeable shears until the
skid retainer snaps in place.

5. Positioning wheels

Replace batteries

1.

Remove cover

Place a coin in the cover slot and press in the direction of the
blade (1). Remove the cover from above (2).

2.

Replace batteries

Remove both plugs from the batteries (3); remove the batteries
from the shears. Place the new batteries in the shears and
connect the two plugs.

3. Fastening the cover

Push the lid with the projection (4) under the edge of the shears
and then press the cover on the shears (5).

3

Note:

Please ensure that no cable protrudes from the shears when
fastening the cover!

Spare parts

Warranty

The warranty rules issued by our company or the importer apply to
every country. As part of the warranty, we remedy malfunctions on
your appliance free of charge provided that this malfunction is
caused by a material or manufacturing defect. In the event of a war-
ranty claim, please turn to your dealer or the nearest branch office.

C

C

D E F G H

J K

D

E

F G H

J

F

H

G

H

J

E

K

L M N

L

M

N

Order designation

Item no.

Product information

AC-TS

Telescopic handle

7095 000

Continuously adjustable from 85-120 cm.
Result: convenient trimming without stooping.
(LI-ION POWER 60 / 80 / 100 / BS 80)

Accu 8 EM

Shear blade

7084 095

Cutting width 80 mm (LI-ION POWER 60 / 80 / 100 / BS 80)

Accu 10 EM

Shear blade

7085 095

Cutting width 100 mm (LI-ION POWER 100 / BS 80)

Accu BS EM

Shrub blade

7095 095

Length 170 mm (LI-ION POWER 100 / BS 80)

AC-R

Replacement blades

7084 094

Result: The wheels achieve a consistent cutting height
(LI-ION POWER 60 / 80 / 100)

Accu

7084 918
7085 918
7086 918

LI-ION Power 60
LI-ION Power 80
LI-ION Power 100 / BS 80

Charger (UK)

Charger (international)

7085 069
7087 068

LI-ION Power 60 / 80 / 100 / BS 80
