English |

15

The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging procedure
does not damage the battery.
The “Electronic Cell Protection (ECP)” protects the lithium-
ion battery against deep discharging. When the battery is
discharged, the machine is switched off by means of a pro-
tective circuit: The garden product no longer operates.

Note

: The micro-USB port

(11)

 for connection of the micro-

USB cable

(9)

 is in the handle.

When the charger level indicator

(1)

 lights up red, the bat-

tery must be charged. Switch the machine off and charge the
battery.
Connect the machine to the charger

(10)

 using the micro-

USB cable

(9)

. Plug the charger

(10)

 into the socket. The

charging process begins.
During the charging procedure, the handle of the machine
warms up. This is normal.
The charger level indicator

(1)

 continuously lights up red

during the charging procedure. When the battery is com-
pletely charged, the charger level indicator

(1)

 goes out.

Disconnect the battery charger from the mains supply when
charging process ends.
Observe the notes for disposal.

Mounting/Removing the Blade (see figures C)

Press the release button

(12)

 and slide the cover

(5)

 toward

the rear. Remove the cover

(5)

 from the housing.

Tilt the blade

(6)

/

(7)

 upward and then remove the blade

(6)

/

(7)

.

Align the recesses on the blade

(6)

/

(7)

 against the holding

pins and then tilt the blade

(6)

/

(7)

 downward.

Mount the cover

(5)

 again and then slide it toward the front

until it engages.

Operation

u

Make sure that the cover of the USB port

(2)

 is shut dur-

ing operation. This prevents the penetration of dust.

u

Do not use a damaged blade (e.g. cracks, etc.). Replace a
damaged blade immediately.

Switching On and Off (see figure D)

Press and hold the lock-off button

(4)

 and actuate the On/

Off switch

(3)

.

Release the lock-off button

(4)

.

When actuating the On/Off switch

(3)

, the LED continuously

lights up green.

Battery Charge Indicator

LED

Capacity

LED continuously lights up green

33−100 %

LED continuously lights up red
while On/Off switch is halfway
pressed.

0−33 %

Cutting Shrubs (only Shrub Shear)

u

Make sure that the product is switched off when removing
cut-off material or during maintenance. Unintentional
switching on may cause serious injury.

Before cutting check the hedge/shrub for foreign objects
e. g. wire fences.
Cut stems up to 8 mm in thickness. When cutting, move the
product steadily along the line of cut, so that stems are fed
directly into the cutter blades. The double edge of the cut-
ting blade enables cutting to either direction, or with a side
to side motion.
After use, mount the blade guard.

Recommended times

Cut hedges with deciduous leaves in June and October.
Cut evergreen hedges in April and August.
Cut conifer and other fast growing shrubs approx. every six
weeks from May onwards.

Cutting Edges (only Grass Shear)

Guide the product along the edge of the lawn. Prevent the
blade from coming into contact with paved paths, stones or
garden walls because this significantly reduces the lifetime
of the blade.
After use, mount the blade guard.

Troubleshooting

Problem

Possible Cause

Corrective Measure

Cutting time per bat-
tery charge too low

Battery close to end of service life.

Contact Service Agent.

Charger level indicator
lights up red and the
product cannot be
switched on.

Battery temperature too high

Ambient temperature too high Do not expose the
product to direct sunlight. Wait 10–15 minutes to
let battery cool down.
