Toshiba RAS-07 - Инструкция по эксплуатации - Страница 5

TIMER OPERATION

14

Set the timer when the air conditioner is operating.

Setting the ON Timer

Setting the OFF Timer

1

Press

  : Set the desired ON

timer.

Press

  : Set the desired

OFF timer.

2

Press

   : Set the timer.

Press

 : Set the timer.

3

Press

 : Cancel the timer.

Press

 : Cancel the timer.

Note:

●

Keep the remote control in accessible transmission to the indoor unit;
otherwise, the time lag of up to 15 minutes will occur.

●

The setting will be saved for the next same operation.

PRESET OPERATION

15

Set your preferred operation for future use. The setting will be memorized by
the unit for future operation (except air

fl

 ow direction).

1.  Select your preferred operation.

2.  Press and hold

PRESET

 for 3 seconds to memorize the setting.

The

P

 mark displays.

3. Press

PRESET

 : Operate the preset operation.

DISPLAY LAMP BRIGHTNESS ADJUSTMENT

16

To decrease the display lamp brightness or turn it off.

1.  Press and hold

 for 3 seconds until brightness level (

,

,

 or

) is shown on remote control LCD then release the button.

2. Press

Rise

TEMP.

 or

TEMP.

Decrease

 to adjust brightness in 4 levels.

Remote control

LCD

Operation display

Brightness

Lamp illuminates full brightness.

100%

Lamp illuminates 50% brightness.

50%

Lamp illuminates 50% brightness and the
operation lamp is turned off.

50%

All lamps are turned off.

All turned off

●

In the examples of

 and

, the lamp illuminates for 5 seconds before

going off.

For comfortable sleep, automatically control air

fl

 ow and automatically turn OFF

(Except in DRY mode).

1.   Press

 : Select 1, 3, 5 or 9 hrs for OFF timer operation.

2.   Press

 to cancel the comfort sleep operation.

Note:

   The cooling operation, the set temperature will increase automatically

1 degree/hour for 2 hours (maximum 2 degrees increase). For heating
operation, the set temperature will decrease.

COMFORT SLEEP OPERATION

11

HADA CARE FLOW
Air

fl

 ow upward to the ceiling, provide Indirect air

fl

 ow to body and homogenize

room temperature.

HADA CARE FLOW operation

Press

 For start and stop HADA CARE FLOW

Cancel

HADA CARE FLOW

HADA CARE FLOW

Note:

●

During HADA CARE FLOW mode, FIX and SWING button cannot active

HADA CARE FLOW OPERATION

12

Power-Selection (

)

This function is used when the circuit breaker is shared with other electrical
appliances. It limits the maximum current and power consumption to 100%, 75%,
or 50% and can be implemented by POWER-SELECTION. The lower percentage,
the higher saving and also longer compressor lifetime.

Note:

●

When the level is selected, POWER-SEL level

fl

 ashes on remote LCD

display for 3 seconds.
In case of 75% and 50% level, number “75” or “50” also

fl

 ashes for

2 seconds.

●

Due to the reason that POWER-SELECTION function limits the
maximum current, inadequate cooling or heating capacity may occur.

Silent Operation (

)

Keep outdoor unit operating silently to ensure either yourself or neighborhood
will have a tight sleep in nighttime. By this feature, the heating capacity will be
optimized to deliver such silent experience. The silent operation can be selected
from one of two purposes (Silent 1 and Silent 2).
There are three setting parameters: Standard level > Silent 1 > Silent 2

Silent 1:

Though operating silently, the Heating (or Cooling) capacity is still prioritized to
ensure having suf

fi

 cient comfort inside the room.

This setting is a perfect balance between the Heating (or Cooling) capacity and
the Sound level of outdoor unit.

Silent 2:

Compromising the Heating (or Cooling) capacity to the Sound level in any
circumstance where the outdoor unit’s sound level is highly prioritized.
This setting has a purpose to reduce the maximum sound level of outdoor unit by
4 dB(A).

Note:

●

While activating of Silent operation, inadequate heating (or cooling)
capacity may occur.

Power-Selection and Silent Operation (Outdoor Unit)

POWER-SELECTION AND SILENT
OPERATION (OUTDOOR UNIT)

13

[100%]

[75%]

[50%]

SILENT#2

SILENT#1

AUTO RESTART FUNCTION SETTING

17

This product is designed so that, after a power failure, it can restart automatically
in the same operating mode as before the power failure.

Information

The product was shipped with Auto Restart function in the OFF position.
Turn it ON as required.

How to turn ON the Auto Restart Function

●

   Press and hold the [OPERATION] button on the indoor unit for 3 seconds

(3 beep sounds and OPERATION lamp blink 5 time/sec for 5 seconds).

How to turn OFF the Auto Restart Function

●

   Press and hold the [OPERATION] button on the indoor unit for 3 seconds

(3 beep sounds but OPERATION lamp does not blink).

Note:

●

   In case of ON timer or OFF timer are set, AUTO RESTART OPERATION

does not activate.
