www.timberk.com • Electric air conditioner

10

9. TROUBLESHOOTING

Failures and their possible reasons:

Failure

Possible reason

Actions

The conditioner does

not work

Interruptions in power supply

Wait for restoration of power
supply

Batteries in the remote control
board are low

Replace the batteries

Time of tuming on is set by
the timer

Wait till the conditooner turns
on by the timer or cancel the
timer setting

Insufficient cooling or

heating capacity

The set air temperature is too
high or too low

Set the air temperature
correctly

The air filter is clogged with dust

    Clean the air filter

Foreign objects block the air intel
and retum air grillages of the
outdoor unit

     Remove foreign objects

The conditioner works,

but does not cool or

heat the room

A three-minute delay of
compressor tuming on

     Wait a little

The air temperature is set
incorrectly

Set the temperature correctly

10. TRANSPORTATIOM AND STORAGE

Temperature

requirements*
Humidity

requirements*

We are exploring new technologies and we constantly improving the quality

of our products. That’s why specifications, design and accessories are

subject to change without any specific notice.

* This product must have storage in dry, well-ventilated space of warehouse

at the temperature not lower than -30°

Transportation and

storage

From -30° to +50°

From 15% to 85%

(without a condensate)

11.SERVICE LIFE

12. UTILIZATION RULES

Service life of the appliance is 10 years provided that the respective

installation and operation rules are observed.
Date of the conditioner manufacture is shown in a serial number of the

device. For more details, please, ask a shop assistant.

Upon expiration of the service life, the appliance should be utilized in

accordance with norms, regulations and procedures effective in the place

of utilization.

To remove the filter, open the air inlet of the indoor unit panel. Press the

locks to the center and pull the grillages down. Remove the air inlet.

Remove the air filter. Clean the filter with a vacuum cleaner or rinse it in

clean water. If the filter is contaminated heavily, clean it with a soft brush

and wash in diluted washing solution, then dry it in a cool place.
While cleaning the filter with the vacuum cleaner, hold it with contaminated

surface up. While washing the filter in water, hold it with contaminated

surface down.
Do not dry the filter in the sun or near a fire.
Set the air filter to initial position and close an air inlet cover
