www.timberk.com • Electric air conditioner

6

Control panel for  (Fig. 7)
1. POWER button. Press this button to switch on or off the unit.
2. SET button. Press this button to select the mode of heating,

dehumidification or cooling.
3. TEMP up button. In the cooling mode each press of this button

raises the set temperature by 1°C up to maximum 30°C. In the heating

mode each press of this button raises the set temperature by 1°C up to

maximum 25°C.
4. TEMP down button. In the cooling mode each press of this button

lowers the set temperature by 1°C up to minimum 17°C. In the heating

mode each press of this button lowers the set temperature by 1°C up

to minimum 15°C.

CONTROL PANEL & DESCRIPTION OF FUNCTION

Fig. 7.

7. OPERATING MODES

NOTICE:

When the dry mode is working this key is not
used.

NOTE:

While pressing and holding the keys up and
down switches to temperature readings in F
(Farinheit) or C (Celsius) and back.

7. Programmable timer on/off button.

 ON timer.

 The ON timer is used

to automatically switch on the unit upon expiration of the set time.

5

7

6

3

4

2

1

9

8

Fig. 8.

5. LCD display. The display shows the set temperature or the timer.

After the temperature and time are set the display returns to indicating

the current temperature.
6. FAN speed button. Press this button to select low, medium, high or

automatic fan speed button. When the automatic speed is selected

(in the cooling mode), high, medium or low speeds are selected

automatically depending on the difference between the set temperature

and the room temperature.
