8

Electric  air conditioner (split system)

EN

1.  Button «TEMP UP». Increase the

temperature or time by 1 unit.

2.  Button «TEMP DN». Decrease the

temperature or time by 1 unit.

3.  Button «ON/OFF». To switch the

conditioner on and off.

4.  Button «ECO». In cooling mode,

press this button, the tempera

-

ture will increase 2 °С

 on the

base of setting temperature. In

heating mode, press this button,

the temperature will decrease

2 °С on the base of setting

temperature.

5.

Button «MODE». To select the

mode of operation.

6.  Button «SLEEP». To activate the

function «SLEEP».

7.

Button «FAN». To select the fan

speed of auto/low/mid/high.

8.  Button «SWING». To activate or

deactivate of the movement of

the deflectors.

9.

Button «HEALTH». To switch –

on /off HEALTH funtion. It is a

button which controls the ionizer

or plasma generator only for

inverter type.

Fig. 3

Remote control

10. Button «TURBO». In cooling mode, press this button, the unit will give the

maximum cooling temperature. In heating mode, press this button, the

unit will give the maximum heating temperature.

11. Button «DISPLAY». To switch on/off the LED display (if present).
12. Button «TIMER». To set automatic switching on/off.

1

3

6

9

4

8

5

7

2

SWING

SWING

SLEEP

FAN

TURBO

TIMER

ECO

MODE

DISPLAY

HEALTH

12

10

8

11
