9. Calculate the amount of all refrigerant filling in this system.---(7)

Table 1) Capacity and amount of refrigerant of the indoor unit (Show-

case and Blower coil)

Note

1. Case of showcase, the condition of capacity (evaporating tempera-

ture)
Refrigeration :-10°C
Frozen

:-35°C

2. Case of blower coil, the condition of capacity is 10°C (Td).

Table 2) The amount of refrigerant of the indoor unit for air-conditioning

*Calculate for each unit.

**The total amount of refrigerant for air conditioning can’t exceed

4.1 kg.

***In case a mix of VRV indoor and air curtains is installed the capacity

indoor ratio of the air curtains is 45% or less of the total connected
capacity indoor.

Figure 1)

Inch piping

Metric piping

Liquid
pipe
size


Refrig-
erant
amount

Liquid
pipe
size


Refrig-
erant
amount

Pipe
length
(m)

Total
amount
of refrig-
erant
 (kg)

Ø6.4

0.02

Ø6.0

0.018

(a)

Ø9.5

0.06

Ø10.0

0.066

(b)

Ø12.7

0.12

Ø12.0

0.097

(c)

Ø15.9

0.19

Ø16.0

0.19

(d)

(1) Subtotal [(a)+(b)+(c)+(d)]

Indoor unit

Total
capacity
(kW)

Amount
of
refriger-
ant
(Refer to
table 1
and 2)

Refrigeration showcase

(A)

Frozen showcase

(B)

Blower coil

(C)

Air-conditioning unit

(D)

(2) Subtotal [(A)+(B)+(C)+(D)]
(3) Constant amount of additional filling

3.5

(4) Total of the amount of refrigerant

replenishment [(1)+(2)+(3)]

(5) Amount of refrigerant replenishment at the

time of test run.

(6) Amount of initial filling

11.5

(7) Total additional charging amount

[(4)+(5)+(6)]

Total capacity of showcase or
blower coil
 (*Note.)

Amount of refrigerant (kg)

Showcase

Blower coil

Refrigeration

Frozen

Less than 5kW

1.1

1.4

0.6

From 5kW to less than 10kW

2.3

3.2

1.2

From 10kW to less than 15kW

3.4

5.2

1.7

From 15kW to less than 20kW

4.6

—

2.3

20kW or more

5.9

—

3.0

Indoor unit

Outdoor unit

Blower coil

Booster unit

Refrigeration
showcase

Frozen
showcase

VRV indoor

50

63

71

80

FXFQ-A

0.7 kg

0.7 kg

—

0.9 kg

FXUQ-A

—

—

0.8 kg

—

FXHQ-A

—

0.9 kg

—

—

FXKQ-MA

—

0.7 kg

—

—

FXCQ-A

0.5 kg

0.7 kg

—

0.8 kg

FXSQ-A

0.3 kg

0.6 kg

—

0.5 kg

FXMQ-P

0.5 kg

0.7 kg

—

0.7 kg

FXMQ-MB

—

—

—

—

FXLQ-P

0.8 kg

0.8 kg

—

—

FXNQ-A

0.8 kg

0.8 kg

—

—

VRV indoor

100

125

200

250

FXFQ-A

0.9 kg

1 kg

—

—

FXFQ-A

0.9 kg

1 kg

—

—

FXUQ-A

0.8 kg

—

—

—

FXHQ-A

1.1 kg

—

—

—

FXKQ-MA

—

—

—

—

FXCQ-A

—

1.1 kg

—

—

FXSQ-A

1 kg

1 kg

—

—

FXMQ-P

1.2 kg

1.2 kg

—

—

FXMQ-MB

—

—

2.1 kg

2.4 kg

FXLQ-P

—

—

—

—

FXNQ-A

—

—

—

—

Biddle Air Curtain

Refrigerant charge

CYVS100DK80*

1.0 kg

CYVS150DK80*

1.5 kg

CYVS200DK100*

1.9 kg

CYVS250DK140*

2.4 kg

CYVM100DK80*

1.0 kg

CYVM150DK80*

1.5 kg

CYVM200DK100*

1.9 kg

CYVM250DK140*

2.4 kg

CYVL100DK125*

1.4 kg

CYVL150DK200*

2.1 kg

CYVL200DK250*

2.9 kg

CYVL250DK250*

3.6 kg

Full of
liquid

Bubbles come
out at all times.

A few
bubbles
flow.

Sealed state (    )

Shortage of refrigerant (    )
