• 8 •

Key to Machine Parts (Page 2)

1

Control panel

2

Water tank lid

3

Hot water / steam knob

4

Seat for accessories

5

Water tank

6

Cup holder surface

7

Water recovery tray + grill (if any)

8

Coff ee brew unit

9

Steam wand

10

Power cord

11

Pressurized fi lter holder

12

Ground coff ee measuring scoop

13

Ground coff ee fi lter

(single piece for 1 or 2 coff ee(s))

14

ON/OFF button

15

"Machine on" indicator light

Light ON = the machine is on

Light OFF = the machine is off

16

Coff ee brew button

17

Coff ee/water - "Machine ready" indicator light

Light ON = OK for coff ee brewing / hot water dispensing

Light OFF = temperature is too low for coff ee brewing /
hot water dispensing

18

Steam button

19

"Steam ready" indicator light

Light ON = OK for steam dispensing

Light OFF = temperature is too low for steam dispensing

4   INSTALLATION

For your own and other people safety, carefully follow
the "Safety Regulations" indicated in chapter 3.

4.1 Packaging

The original packaging has been designed and manufactured
to protect the machine during transport. We recommend keep-
ing the packaging material for possible future transport.

4.2 Installation

Precautions

Before installing the machine, read the following safety pre-
cautions carefully:
•  Place the machine in a safe place.
•  Make sure children cannot play with the machine.
•  Do not place the machine on hot surfaces or near open

fl ames.

The coff ee machine is now ready to be connected to the electric
network.

Note: We recommend washing the components
before using them for the fi rst time and/or af-

ter they have not been used for a certain period of time.

4.3 Water

Tank

•

(Fig.1A) -

Remove the lid from the water tank (2) by lifting

it.

•

(Fig.1B) -

Remove the water tank (5).

Note: The machine accessories are placed on
the water tank's (5) side.

•

(Fig.2) -

Rinse the water tank and fi ll it with fresh drink-

ing water: do not exceed the (MAX) level indicated on the
water tank.

Fill the tank only with fresh, non-sparkling,
drinking water. Hot water or any other liquid

may damage the tank. Do not operate the machine
without water: make sure that there is enough water in
the tank.

•

(Fig.3) -

Insert the water tank making sure that it has

been properly repositioned in its former seat and then
reposition the lid (2).

Make sure that the tank is fully inserted in the
machine by pressing it gently up to its limit stop

(THE REFERENCE MARK SHOWN IN FIG.4 MUST BE COM-
PLETELY VISIBLE). This is to avoid water leaks from its
bottom.

4.4 Machine

Connection

Electric power may be very dangerous! It is
therefore necessary to strictly follow the safety

regulations. Do not use faulty power cords! Faulty cords
and plugs must be replaced immediately by Authorised
Service Centres.

The voltage of the appliance has been pre-set by the manu-
facturer. Check that the voltage matches the indication on the
identifying data plate at the bottom of the appliance.
•  Insert the plug into a wall socket with suitable power volt-

age.
