14

● While the grinding unit is running, move

the sliding switch 16 to the desired

position: the smaller the dots, the iner the

grind.

i

 The new setting will not become apparent

until the second or third cup is brewed.

Tip: For dark roast coffee beans, choose a

coarser grind; for light roast beans, select a

iner grind.

Float

The loat

22 in the water tray 21 shows

when the tray needs emptying.

● If the loat

22 is clearly visible, empty the

water tray 21.

Preparation

This fully automatic espresso/coffee
machine grinds beans freshly for each
brew. If possible, use only beans for fully
automatic coffee and espresso machines.
Deep-freeze or store in a cool place in
sealed, airtight containers. Coffee beans
can be ground while frozen.
Important: Fill the water tank with fresh
water every day. The tank must always

contain suficient water for operating the

appliance. Do not allow it to become empty.
Tip: Pre-warm cups, especially small, thick
espresso cups, by placing on the cup shelf
15 or rinsing with hot water.

Using coffee beans

The appliance must be ready for use.

● Set the desired per­cup quantity using

dial 2.

● Select the desired coffee strength using

button

5

.

● Place the prewarmed cup(s) under the

coffee outlet 10.

● Press the coffee dispensing button

4

once for 1 cup or twice within three
seconds for 2 cups. The coffee is brewed
and dispensed into the cup(s).

Note
If you select two cups, the grinding and
brewing process is per formed twice.

● Coffee dispensing stops automatically

when the selected quantity has been
dispensed.

i

 The brewing process can be terminated

by pressing the coffee dispensing button

4

 again. When coffee is brewed for

2 cups, it is dispensed via two outlet
nozzles (place the cups side by side).

Using ground espresso/
coffee powder

The appliance must be ready for use.

● Set the desired per­cup quantity using the

dial 2.

● Place the prewarmed cup(s) under the

coffee outlet 10.

● Open the cover of the ground coffee duct

14.

● Add

one to two level scoops of ground

coffee (grind: medium­ine) to the ground

coffee duct 14.

Note
Do not add whole beans or instant coffee!
Use a maximum of two level scoops of
coffee.

● Close the cover of the ground coffee duct

14.

● Press the coffee dispensing button

4

.

i

 Repeat the process if a second cup is

desired.

Note: If coffee is not brewed within 90
seconds, the brewing chamber is emptied

automatically in order to prevent overilling.

The appliance is rinsed.

en
