6. OPERATION

Install the device on a firm and stable surface or tripod.

Move the switch bar to select the required operation mode:

1) Unlocked mode (self-leveling)

Move the switch bar to position

ON

.

The laser level will switch on.
Short press             to switch on required laser lines.
Short press             to switch on/off the pulse mode.
Move the switch bar to position

OFF

to switch off the laser level.

2) Locked mode (projection of inclined planes)

The switch bar is in position

OFF

.

Press and hold                 during 3 seconds to switch on the laser.
Long press               to switch on required laser lines.
After all possible combinations of lines are switched on, the next long
press               will switch off the laser level.
Press and hold                during 3 seconds to switch on/off the pulse
mode.

Note:

 To increase the operating time and avoid the risk of

unintentional blinding switch on the laser only before start operation.

If operated near objects or airflows different from the environment

temperature the laser line may tremble due to heterogeneity of the

atmosphere. The longer the distance, the more trembling can be

observed.

The width of the laser line increases with the increasing of the

operating distance. The marking should be made along the axis of the

laser line. For maximum accuracy, use the middle portion of the laser

line.

It should be noted that the shape of the laser line on the object’s

surface (e.g. walls, ceilings) depends on the curvature and slope of the

surface relative to the laser plane.
