Product Features

The numbering of the product features shown refers to the illustration of the measur-
ing tool on the graphic page.

1

Display

2

Measuring button [

]

3

Minus button [

–

]

4

Function button [

Func

]

5

On/Off button [

]

6

Plus button [

+

]

7

Battery lid

8

Latch of battery lid

9

Serial number

10

Laser warning label

11

Reception lens

12

Laser beam outlet

13

Laser target plate *

14

Laser viewing glasses *

* The accessories illustrated or described are not included as standard delivery.

Display Elements

a

Laser, switched on

b

Temperature warning

c

Battery low indicator

d

Value

e

Unit of measure

A) For measurements from the rear measuring tool edge, weak backlighting and 25 ° C operating
temperature are applicable for high reflectivity of the target (e. g. a white-painted wall). In addition,
a deviation influence of ± 0.05 mm/m must be taken into account.

B) For measurements from the rear measuring tool edge, strong backlighting and – 10 ° C to + 45 ° C
operating temperature are applicable for low reflectivity of the target (e.g. a black box). In addition,
a deviation influence of ± 0.15 mm/m must be taken into account.

C) At 25 ° C operating temperature

D) except battery compartment

The measuring tool can be clearly identified with the serial number

9

 on the type plate.
